Blue Ox BX1133 Installation Instructions

Please read BOTH these Installation Instructions and the General Instructions
1. Blue Ox towing products and accessories are
®
intended to be installed by Blue Ox
who are familiar with our products and have the
equipment and knowledge necessary to do "fit
work". If needed, Blue Ox
at www.blueox.com
Care Department at (402) 385-3051.
2. Many Blue Ox baseplates are designed to
®
use existing holes and hardware to mount the
baseplate to the towed vehicle. Even though bolts
are there, do not assume they are adequate for
baseplate mounting. Always use the hardware
supplied in the hardware kit and existing hardware
as specified in the installation instructions.
If the front of your vehicle looks different than
this, please contact us at (402)385-3051.
Reference your vehicle owner's
manual for manufacturer's towing
specifications.
405-00281
2012 Jeep Wrangler Unlimited Call of Duty
prior to installing or operating this equipment.
Dealers
®
Dealers can be found
®
or by contacting our Customer
BX1133
Installation Instructions
Approximate Attachment Tab Height: 18"
Approximate Attachment Tab Width: 24"
Bolt Torque Specifications
Torque in Foot-Pounds for Metric Bolts
Bolt Size Grade 8.8 Grade 10.9
10MM
12MM
14MM
Bolt Torque Specifications
Torque in Foot-Pounds for Inch Bolts
Bolt Size
!
Failure to read and follow these instructions
could result in separation of the towed vehicle
from the tow bar, causing property damage,
loss of towed vehicle, personal injury or death.
Page 1 of 5
6MM 6
8MM 16
31
54
89
Grade 5
1/4" 10
5/16" 19
3/8" 33
7/16" 54
1/2" 78
5/8" 154
WARNING
8
22
40
70
117
Grade 8
14
29
47
78
119
230
8/31/12
