Winegard PROSTAR HD-6000 Engineering Specification

Clearly the World's Best

engineering specifications

Active Elements 4
Boom Length
33"
Turning Radius
39"
Maximum Width 65.5"
Vertical Height
3"
Element Diameter
3/8"
Output Impedance:
Recommended Preamp:
CHANNEL
dB gain over
reference dipole
beamwidth at half
power points
front-to-back
ratio
Printed in U.S.A. Winegard Company, 3000 Kirkwood St., Burlington, IA 52601-2000 Rev. 6/01
®
Net Weight 2 lbs.
Shpg. Weight 3.2 lbs.
Carton Dimensions 6.25"x6.25"x59"
300 ohm / 75 ohm with included transformer
AP Series
88MHz
5
67°
6dB
88MHz
98MHz
5
72°
14dB
POLAR PATTERNS
98MHz
®
PROSTAR
FM
ANTENNA
Model PR-6000
"UPS in shield design is a registered
trademark of United Parcel Service of
America, Inc. used by permission."
Made in U.S.A.
108MHz
5.2
71°
16dB
108MHz
1000
