Winegard Prostar 1000 PR-7010 Engineering Specification

Clearly the World's Best

engineering specifications

Active Elements
22
Boom Length
66.5"
Turning Radius
63.75"
Maximum Width
111"
Vertical Height
19"
Element Diameter
3/8"
Output Impedance:
Recommended Preamp:
CHANNEL CH.2
dB gain over
2.3
reference dipole
beamwidth at half
75°
power points
front-to-back
9dB
ratio
CH.2
CH.13
Printed in U.S.A. Winegard Company, 3000 Kirkwood St., Burlington, IA 52601-2000 Rev. 6/01
®
Net Weight 4.4 lbs.
Shpg. Weight 5.87 lbs.
Carton Dimensions 6.25"x6.25"x68.25"
300 ohm / 75 ohm with included matching transformer
AP Series
CH.4 CH.6 CH.7
3.6 1.9 6.8
77° 77° 36°
9dB 10.5dB 11.5dB
CH. 4 CH.6
CH.14 CH.32
CH.9 CH.11 CH.13
6.8 7.3 6.3
36° 43° 37°
8dB 8dB 10dB
POLAR PATTERNS
CH.7
CH.50
PROSTAR
VHF/UHF/FM
ANTENNA
Model PR-7010
"UPS in shield design is a registered
trademark of United Parcel Service of
America, Inc. used by permission."
Made in U.S.A.
CH.14 CH.32 CH.50
8.1 8 8.3
73° 40° 37°
7dB 12.5dB 19dB
CH.9
CH.69
®
1000
CH.69
7
39°
15dB
CH.11
