Installation Manual Table of Contents 1.0 General Information 1.1 About This Document 1.2 Additional Information and Documents Related to the Camera System 1.3 Copyright/Intellectual Property Rights Statement 1.4 FCC Compliance 1.5 Support Services 2.0 Returns 2.1 Instructions 2.2 Shipment 3.0 Safety 3.1 Instructions 3.2 Grounding 4.0 Package Contents...
Page 4
Installation Manual 11.0 Installation 11.1 Camera System Mounts 11.2 Mounts 11.2.1 Mounting Brackets Dimensions 11.2.1.1 Wall Mount 11.2.1.2 Pole Mount Adapter 11.2.2 Wall Mount Installation 11.2.3 Pole Mount Installation 11.3 Installation Procedure 12.0 System Requirements 12.1 Requirements 12.2 Recommended Computer Specifications 13.0 Optional Accessories 14.0 Service 14.1 Maintenance...
Installation Manual 1.0 General Information 1.5 Support Services Please contact CohuHD Customer Service Department for technical assistance at (858) 391-1800 option 2.
Installation Manual 2.0 Returns 2.0 Returns 2.1 Instructions This item was thoroughly tested and carefully packed at the factory prior to shipping. Upon acceptance by the carrier, the carrier assumes responsibility for the item’s safe arrival. If you receive the item in a damaged condition, apparent or concealed, a claim for damage must be made to the carrier.
Installation Manual 3.0 Safety 3.0 Safety 3.1 Instructions Warning: Do not remove the covers or housing. There are no user-serviceable parts inside. Warning: The Schrader Valves on the camera head's back plate are for factory use only. Do not attempt to add any gas to the camera head.
Installation Manual 3.0 Safety 3.2 Grounding To provide protection against electrical surges induced by lightning, static charges, or any other cause, the camera must be properly grounded to earth. For installation on a building, the camera must be bon- ded (that is, provided with a low impedance connection) to the building’s structural earth ground sys- tem.
Installation Manual 4.0 Package Contents 4.0 Package Contents Upon opening of the products shipping package, please verify you have received the following items: 1. CohuHD 4220HD Camera System 2. Pigtail Cable, MS to RJ45, 3ft (1) * 3. RISE Accessory Kit: Nitrile Gloves (2) Anti-Seize Compound (1) 4.
Installation Manual 5.0 Product Overview 5.0 Product Overview The 4220HD Series Camera System is an IP camera system inside an environmentally sealed and pressurized dome enclosure. The camera system provides IP video streams with H.264 and MJPEG compression. The positioning system provides continuous 360°...
Installation Manual 6.0 Factory Defaults 6.0 Factory Defaults 6.1 Factory Default IP Address and Settings The camera is shipped with the following network settings: IP Address: 192.168.2.150 Subnet mask: 255.255.255.0 Gateway: 192.168.2.1 6.2 User Names and Passwords Note: The camera is no longer shipped with a username and password. The first user is admin who has to create a password and then login.
Installation Manual 7.0 Camera URLs 7.0 Camera URLs 7.1 Camera Default Passwords User = admin Password = admin 7.2 Network Video Ports Required for RTSP 554 - RTSP uses TCP or UDP as its transport protocol. Unicast Video - Starting at 30000 up to 31000 Multicast Video - User configurable port through web interface 7.3 Video Stream Connection URL’s Note: Do not include brackets <...
Installation Manual 7.0 Camera URLs 7.4 Network Ports 80 Web Server 123 Time Server 554 RTSP Server 3244 CohuHD Log Server 3702 Onvif Discovery 4222 Secure Shell 16568 Rise Discovery 65532 CohuHD Diagnostic 7.5 Camera Control Ports 1233 CohuHD Legacy Camera Control Protocol 1234 CohuHD Legacy with 4 Byte Message Length Header Camera Protocol 1237 CohuHD T Camera Control 1238 F.A.S.T.
Installation Manual 8.0 Connections 8.0 Connections 8.1 Interconnections The following are interconnection diagrams for the 4220HD Series camera system: 8.1.1 Interconnection Diagram for 4220-1000 and 4228-1000 8.1.2 Interconnection Diagram for 4224-1000 CohuHD provides a wide selection of factory built and tested Ethernet and system cables providing high quality and reliable interconnection of CohuHD cameras and system control products.
Installation Manual 8.0 Connections 8.2 Manufactured Cables Available Models 4220-1000 and 4228-1000 are shipped with a 45-inch Cat5e pigtail cable (CohuHD p/n 8196402-001) and a coupler (CohuHD p/n 7610203-002). Important: For proper sealing, the diameter of the ethernet cable jacket must be 6 mm or 8 mm. Note: Typically, Unshielded cable is used for most projects unless Shielded cable is specified.
Installation Manual 8.0 Connections 8.3 Schematics 8.4 18-pin MS Connector and its Mating System Cable Connector All system electrical connections for the 4220HD Series route through an MS-type metal connector installed in the dome housing. Integral Camera connector: CohuHD p/n 1310225-212. Field Cable Mating connector: CohuHD p/n 1310230-212 (supplied, if ordered).
Installation Manual 8.0 Connections 8.5.3 Wiring Digital Inputs/Outputs (DIO) The following are interconnection diagrams for the DIO circuits of the 4220HD Series camera system for input and output device applications. Refer to appropriate 4220HD model number connector pinout diagram for pin number.
Installation Manual 8.0 Connections 8.6 Field Cables All Ethernet wiring must be done in accordance with TIA/EIA 568-C standards. To connect two outdoor Cat5e cables together use a waterproof coupler. For proper sealing, the dia- meter of the network cable jacket must be 6 or 8 mm. To build the camera system cables, CohuHD recommends: For Ethernet/PoE++: CohuHD p/n 7610179-001 or equal.
Installation Manual 8.0 Connections For 24 V Power: Two wires, insulated for 300 V minimum, 18 AWG cord for power. Use for distances up to 80 feet (29 m) for 24 V cables. Note: Long cable lengths and/or low mains voltages can cause the 24 V power at the camera power pins to drop below the minimum input voltage of 21.6 V (24 V -10%) resulting in unreliable operation.
Installation Manual 9.0 Waterproof Coupler Assembly 9.0 Waterproof Coupler Assembly 9.1 Parts The coupler comes assembled with extra two large diameter cable seals for thicker cables. The coupler package consists of the following parts: 1. Sealing Nut (2 pcs) 2. Seal a.
Page 24
Installation Manual 9.0 Waterproof Coupler Assembly 2. If the RJ45 plug has a strain-relief boot, push it away from the RJ45 plug. The strain-relief boot will not be used. 3. Pass the cable through the Sealing Nuts (1) 4. Pass the cable through the Sealing Collar (3). 5.
Page 25
Installation Manual 9.0 Waterproof Coupler Assembly 10. Now attached the Sealing Nut (1) to the connected Sealing Collar (6). Warning: Tighten by hand and do not over-tighten. Using tools and over-tightening may split the Seal’s notch, which compromises the waterproof assembly. The Seal’s notch should join without a flaw.
Installation Manual 10.0 Best Practices 10.0 Best Practices The purpose of this section is to provide recommendations regarding the proper selection and use of Surge Protection Devices (SPDs) in CCTV systems. This document is not meant to provide guidance for SPDs selection, placement, and use on incoming utility power.
Installation Manual 11.0 Installation 11.0 Installation 11.1 Camera System Mounts The 4220HD Series is designed for outdoor installation. For installation: Use stainless steel (SS) hardware to fasten the camera system to the mounting bracket and mounting brackets to surfaces. Use anti-seize compound in order to prevent galling on the threads. CohuHD recommends ®...
Installation Manual 11.0 Installation 11.2.3 Pole Mount Installation Use the mount adapter, wall mount, and large pole mount for installation to a pole. 11.3 Installation Procedure Caution: Do not use the cable to support the weight of the camera. Provisions must be made for routing the system cable up to the camera system location: Pole: If the cable routes up through the pole, support the cable inside the pole to strain relieve the cam- era connector.
Page 30
Installation Manual 11.0 Installation Route the pigtail cable down through the nipple and attach the pigtail cable plug to the dome con- nector. Route the system cable down through the nipple and attach the system cable plug to the dome connector.
Installation Manual 12.0 System Requirements 12.0 System Requirements 12.1 Requirements In order to test the camera system you need the following items: Laptop or desktop computer 100/1000BASE-T network card installed in the computer Microsoft Internet Explorer, version 11 or later web browser 100/1000BASE-T network switch or hub Cat5e or Cat 6 cable 12.2 Recommended Computer Specifications...
Installation Manual 13.0 Optional Accessories 13.0 Optional Accessories The following optional accessories are recommended by CohuHD and can be purchased with the camera system. Mounts Wall: CohuHD p/n 7411420-001 Pole: CohuHD p/n 8518-2 Cables Refer to 4220HD CohuHD-Manufactured System Cables. Mid-Span PoE++ Injectors 100 V - 240 V: p/n 7412007-003 Field Connector...
Installation Manual 14.0 Service 14.0 Service The 4220HD series is designed for long-term unattended use and contains no user-serviceable parts. In the event of product failure, the system should be removed from the site and returned to an authorized service center for repair.
Installation Manual 14.0 Service 14.2 Troubleshooting The table below identifies possible issues that could occur with the camera, and corrective actions on how to resolve them. If the issue persists after following the corrective actions, contact CohuHD field service department at (858) 391-1800 option 2 for additional assistance. Problem/Symptom Possible Cause Correction...
