Winegard HD7082P Specifications
Winegard HD7082P Specifications

Winegard HD7082P Specifications

Platinum series high definition vhf/uhf antenna

Advertisement

Quick Links

Clearly the World's Best
engineering specifications
Active Elements
50
UHF Elements
32
VHF Elements
18
Boom Length
110.5"
Turning Radius
70.6"
Maximum Width
110"
Vertical Height
19.3"
Element Diameter
3/8"
Output Impedance:
Recommended Preamp:
GAIN
CH.2
dB over reference
6.4
dipole
beamwidth at half
76°
power points
front-to-back
15dB
ratio
Printed in U.S.A. Winegard Company, 3000 Kirkwood St., Burlington, IA 52601-2000 Rev. 4/02
®
Shpg. Weight
10.8 lbs.
Carton Dimensions
6 . 2 5 " x 6 . 2 5 " x 8 9 "
75 ohm
AP Series
CH.4
CH.6
CH.7
6.4
6.2
10
71°
73°
35°
20dB
19dB
13dB
CH.9
CH.11 CH.13
10.9
10.2
10
40°
44°
51°
greater
20dB
20dB
than
20dB
POLAR PATTERNS
PLATINUM SERIES
HIGH DEFINITION
VHF/UHF
ANTENNA
Model HD7082P
"UPS in shield design is a registered
trademark of United Parcel Service of
America, Inc. used by permission."
Made in U.S.A.
CH.14
CH.32 CH.50
13
12.2
10.8
31°
40°
39°
greater
10.5dB
than
20dB
20dB
CH.69
12.2
21°
16dB
