Winegard HD7080P Specifications

Clearly the World's Best
engineering specifications
Active Elements 39
UHF Elements
25
VHF Elements
14
Boom Length 90"
Turning Radius
61.7"
Maximum Width
110"
Vertical Height
19.3"
Element Diameter
3/8"
Output Impedance:
Recommended Preamp:
GAIN CH.2
dB over reference
5.1
dipole
beamwidth at half
75°
power points
front-to-back
13dB
ratio
Printed in U.S.A. Winegard Company, 3000 Kirkwood St., Burlington, IA 52601-2000 Rev. 4/02
®
Shpg. Weight 9.5 lbs.
Carton Dimensions 6.25"x6.25"x101"
75 ohm
AP Series
CH.4 CH.6 CH.7
5 2.8 7.6
77° 77° 36°
13dB 11dB 15dB
CH.9 CH.11 CH.13
9.5 9.2 11
42° 45° 39°
greater greater
19dB
than than
20dB 18dB
POLAR PATTERNS
PLATINUM SERIES
HIGH DEFINITION
VHF/UHF
ANTENNA
Model HD7080P
"UPS in shield design is a registered
trademark of United Parcel Service of
America, Inc. used by permission."
Made in U.S.A.
CH.14 CH.32 CH.50
11.7 11.4 11
45° 46° 41°
greater
13dB 20dB
than
20dB
CH.69
10.2
35°
14dB
