Winegard HD-9095P Specifications

Clearly the World's Best

engineering specifications

Active Elements 3 9
Boom Length
9 5 "
Turning Radius
9 2 . 7 5 "
Maximum Width 2 7 "
Vertical Height
3 1 . 7 5 "
Element Diameter
3/8"
Output Impedance:
Recommended Preamp:
CHANNEL
dB gain over
reference dipole
beamwidth at half
power points
front-to-back
ratio
Printed in U.S.A. Winegard Company, 3000 Kirkwood St., Burlington, IA 52601-2000 Rev. 2/02
®
Shpg. Weight 8 lbs.
Carton Dimensions 6 . 2 5 " x 6 . 2 5 " x 5 9 "
75 ohm
AP Series
CH.14 CH.32
14.2 16
43° 41°
11dB 14dB
CH.14 CH.32
CH.50
15.5
30°
11dB
POLAR PATTERNS
CH.50
PLATINUM SERIES
HIGH DEFINITION
UHF
ANTENNA
Model HD9095P
"UPS in shield design is a registered
trademark of United Parcel Service of
America, Inc. used by permission."
Made in U.S.A.
CH.69
12.2
34°
8dB
CH.69
