Winegard HD-8200P Specifications

Clearly the World's Best

engineering specifications

Active Elements 71
UHF Elements
37
VHF Elements
34
Boom Length 177.5"
Turning Radius
100"
Maximum Width
1 1 0 "
Vertical Height
3 1 . 5 "
Element Diameter
3/8"
Output Impedance:
Recommended Preamp:
GAIN CH.2
dB over reference
7
dipole
beamwidth at half
68°
power points
greater
front-to-back
than
ratio
20dB
Printed in U.S.A. Winegard Company, 3000 Kirkwood St., Burlington, IA 52601-2000 Rev. 4/02
®
Shpg. Weight 17 lbs.
Carton Dimensions 6.25"x6.25"x122"
75 ohm
AP Series
CH.4 CH.6 CH.7
7.7 6.4 10.4
68° 66° 29°
greater
greater greater
than
than than
20dB
20dB 20dB
CH.9 CH.11 CH.13
12.6 11 12
34° 42° 41°
greater
than 19dB 18dB
20dB

POLAR PATTERNS

PLATINUM SERIES
HIGH DEFINITION
VHF/UHF
ANTENNA
Model HD8200P
Made in U.S.A.
CH.14 CH.32 CH.50
14.2 13.7 12.2
40° 41° 33°
greater
13dB 20dB than
20dB
CH.69
13
23°
10.5dB
