Winegard HD-7084P Specification Sheet

Clearly the World's Best
engineering specifications
Active Elements 6 8
UHF Elements
4 0
VHF Elements
2 8
Boom Length 1 3 1 "
Turning Radius
8 1 "
Maximum Width
1 1 0 "
Vertical Height
2 5 . 5 "
Element Diameter
3 / 8 "
Output Impedance:
Recommended Preamp:
GAIN CH.2
dB over reference
6.2
dipole
beamwidth at half
69°
power points
front-to-back
20dB
ratio
CH.2
CH.13
Printed in U.S.A. Winegard Company, 3000 Kirkwood St., Burlington, IA 52601-2000 Rev. 4-02
®
Shpg. Weight 13.5 lbs.
Carton Dimensions 6.25"x6.25"x104.25"
75 ohm
AP Series
CH.4 CH.6 CH.7
7.2 7.6 10.9
68° 68° 31°
greater greater
19dB
than than
20dB 20dB
CH. 4 CH.6
CH.14 CH.32
CH.9 CH.11 CH.13
12 10.9 10.8
33° 46° 34°
17dB 15dB 17dB
POLAR PATTERNS
CH.7
CH.50
PLATINUM SERIES
HIGH DEFINITION
VHF/UHF
ANTENNA
Model HD7084P
"UPS in shield design is a registered
trademark of United Parcel Service of
America, Inc. used by permission."
Made in U.S.A.
CH.14 CH.32 CH.50
14.6 12.1 11.8
42° 41° 36°
11dB 20dB 20dB
CH.9
CH.69
CH.69
10.2
22°
12dB
CH.11
