Summary of Contents for TheraSauna Persona TSP3737
- Page 1 Owner’s Manual and Assembly for Model TSP3737...
- Page 2 Health Sauna. We are confident that you will enjoy many benefits of using your TheraSauna Persona for many years to come. Carefully and thoroughly read this manual in its entirety before using your TheraSauna Persona for the first time. We recommend keeping this manual for regular review and future reference.
-
Page 3: Table Of Contents
Table of Contents ●●● CONDITIONS OF USE…………………………………………………………………………..3 GENERAL TECHNICAL CHARACTERISTICS……………………………………………….3 PACKAGING AND INDIVIDUAL PANEL INFORMATION…………………………………...3 PARTS LIST……………………………………………………………………………………….4 INSTALLATION INFORMATION AND ASSEMBLY……………………………………….5-11 DIGITAL CONTROL OPERATION INSTRUCTIONS………………………………………..12 ENJOYING YOUR SAUNA………………………………………………………………..13-14 MAINTENANCE………………………………………………………………………………….14 WARNINGS…………………………………………………………………………………...15-17... -
Page 4: Conditions Of Use
●●● Conditions of Use 1. Outside Ambient Air Conditions for Optimal Operation from +5℃ ~+ 40℃ (+41℉ ~+104℉) 2. Relative humidity ≤ 85% 3. Depression: 700~1060 hpa 4. Main supply: 120V 5. Frequency: 60Hz±1 ●●● General Technical Characteristics 1. Functions processed by microprocessors 2. -
Page 5: Parts List
Bottom Panel Back Panel Parts List ●●● Front Panel Bottom Panel Roof Panel Back Panel Interior Light Side Panels x 2 Side Panels x 2 Bench Panel Roof Panel Front Panel with Glass Bench Panel Light Mounting Screw Light Fixture Bolts 5/16 Hex WARNING!!! -
Page 6: Installation Information And Assembly
●●● Installation Information & Assembly A. Do not plug any other appliances into the outlet with your sauna. B. The sauna should always be placed on a fairly leveled surface. C. The sauna must be placed indoors and in a dry area. D. - Page 7 (4) CONNECTING SIDE PANELS Connect the Side Panels to the Bottom Panels by lining up holes and fastening them with screws. 1. Each Side Panel has a white label to identify which side it is. The panel with "LEFT PANEL" label should be placed on the left side when facing the sauna from the front.
- Page 8 (5) INSTALLING BENCH PANEL Install the Bench Panel by sliding it over the Horizontal Guides on each Side Panel. Be careful not to scratch the Side Panels when doing so. Make sure to position the Bench so that the "BACK" sticker is facing back, the smooth and finished sides of the Bench are facing up and forward.
- Page 9 (6) CONNECTING FRONT PANEL WITH GLASS DOOR Place the Front Panel onto the recessed area where the "FRONT" sticker is. Align with both Side Panels and secure in place by fastening with screws.
- Page 10 (7) PLACING TOP PANEL (ROOF) IN PLACE 1. Put the Top Panel on the assembled panels. 2. Gently place the Top Panel onto the rest of the assembled panels. When all four corners are in place, gently push down the Top Panel until it is snuggly fit over the rest of the panels. 3.
- Page 11 (8) LIGHT INSTALLATION 1. Connect the power cables and feed into hole supplied. 2. Use screw to secure. 3. Place bulb in light and slip in light cover.
- Page 12 HERE IS THE FINISHED PRODUCT! ENJOY YOUR NEW SAUNA!
-
Page 13: Digital Control Operation Instructions
On powering up the sauna, the panel will display sauna internal temperature. Once the TheraSauna® Classic reaches the set temperature, the heat indicator light will turn off to let you know the sauna has reached your desired temperature. This does not mean that the sauna is no longer emitting infrared, but that our patented, StableHeat™... -
Page 14: Enjoying Your Sauna
●●● Enjoying your Sauna INSTRUCTIONS FOR USE Review all health and safety instructions. If in doubt as to the advisability of using your infrared sauna, consult with your physician. If you feel light -headed or heat-exhausted during a session, exit the sauna immediately. -
Page 15: Maintenance
another towel on the floor to absorb extra sweat. A third towel draped over the knees may aid you in comfort and is useful to towel off sweat. 7. Be sure to towel off excess sweat during your session to help the body to perspire more freely. 8. -
Page 16: Warnings
●●● Warnings This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance! Safety Instructions •... - Page 18 THERASAUNA PERSONA MANUAL 1.16.18...
