Williams Sound TEL008 Specification Sheet

RINGMAX ™ Amplified Telephone Ringer •
Description:
Have you been missing important phone calls? You don't have to anymore. If you have difficulty
hearing the phone ring, the RINGMAX can help. The RINGMAX is an amplified phone ringer that
lets you customize your phone ring for better hearing. With the RINGMAX, you can quickly and
easily increase the volume, then set the tone and "warble" to a pitch that's best for you. Four spe-
cially selected tone settings emphasize those frequencies easiest to hear. Total sound output is 95 dB
SPL at 1 meter.
Applications:
• Household • Shop • Garage • Any Noisy Environment
TEL 008 Telephone Ringer:
Dimensions:
Color:
Maximum Volume:
Frequency Range:
Warble:
On/Off Switch:
Line Cord Length:
Plug Type:
Power Supply:
Battery Life:
Approvals:
Warranty:
RINGMAX's Volume & Frequency Range Superiority:
10
20
30
40
50
60
70
125 250 500
Optimal Ring
Frequency Range
The most common type of hearing loss affects chiefly the higher sound frequencies. The left chart graphs a
typical loss profile of this kind. The shaded area indicates the optimal ring frequency range, 250–1000 Hz,
where hearing ability is maximized. On the right is a sound pressure diagram. The blue area maps the RING-
MAX volume (maximum sound energy) at its four tone settings, while the lower mark indicates the lesser vol-
ume and inappropriate frequency range of normal telephone ringers.
*90 days on accessories
NOTE: SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE!
©2008, Williams Sound Corp. CAT 025F
6.1" H, 3.5" W, 1.3" D
(155 mm H, 90 mm W, 32 mm D)
White
95 dB SPL at 1 m , 4 step adjustable
500–1000 Hz, 4 step adjustable
4 step adjustable
Pushbutton
3 m (10 ft)
RJ11, for central office 2-wire connectors
Four (4) AA 1.5 V non-rechargeable Alkaline batteries
(BAT 001)
Approximately one year
FCC, RoHS, WEEE
Two-year, parts and labor*
1000 2000 4000 8000
Frequency (Hz)
Model TEL 008
RINGMAX
10
20
30
40
50
60
70
125 250 500 1000
Optimal Ring
Frequency Range
Normal
Phones
2000 4000 8000
Frequency (Hz)
