Williams Sound PhoneMax TEL 030 Specification Sheet

PhoneMax ™
Description:
The PhoneMax improves speech understanding. By boosting the high frequencies that make speech
understandable, the PhoneMax gives you special help in communicating over the phone. The
PhoneMax's extra loud ringer and flashing ring indicator alert you to incoming calls, while flash and
redial buttons make dialing outgoing calls convenient. The clean white design and high-contrast con-
trols make it an attractive addition to your desktop or wall. Exceptional value, exceptional price!
TEL 030 Amplified Telephone:
Dimensions:
Color:
Wide-Band Acoustic Gain:
Max. HF Acoustic Gain:
Audio Freq. Response:
Sat. Acoustic Output:
Total Harmonic Distortion:
Signal-to-Noise Ratio:
Ringer Volume Control:
Ringer Loudness:
Ringer Pitch Control:
Flasher:
Connections:
Ringer Equiv. No. (REN):
Approvals:
Warranty:
Features & Functions:
Special Handset
Speaker
Provides superior
sound quality
*90 days on accessories.
NOTE: SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE!
©2007, Williams Sound Corp. CAT 081C
Amplified Telephone •
2.2" D, 8.9" H, 7.6" W (56 mm D, 226 mm H, 192 mm W)
White with dark gray controls
17 dB maximum
25 dB
300 Hz to 2800 Hz, ± 3 dB
112 dB SSPL
< 3% at 105 dB SPL output, 1000 Hz
51 dB, NAB weighted
Hi, Lo, Off
80-85 dBA SPL at 1 meter (Hi position)
Adjustable, 3 positions (lo, med, hi)
High visibility red neon lamp
2-wire central office connection, modular plug
1.0B
WEEE
Five years, parts and labor*
Volume
Control
Boosts volume
up to 25 dB
Model TEL 030
Pulse/Tone Switch Big Buttons
Toggles between Pulse and Easy to see
Touch-Tone dialing modes and use
VOLUME RINGER FLASH REDIAL
SOFT LOUD
Flashing Ring Flash Button
Indicator Interrupts line for
0.5 second for
Flashes red to
call waiting or
indicate ring
three–way calling
1
Ringer
Tone
Control
Adjustable
to meet
your
individual
needs
Ringer
Volume
Control
Adjusts ringer
volume
(Hi, Lo & Off)
Redial Button
Automatically
redials last
number called
®
