Williams Sound TGS R30 Specifications

FM Tour Guide
Description:
The TGS R30 Receiver is a single-channel, FM wideband receiver operating on the 72-76 MHz bandwidth. This
low-cost, easy-to-use receiver includes two AA batteries for 80 hours of long-lasting operation. It features a
volume control/on/off dial, earphone/charging jack and LED power indicator.
Applications:
• Churches • Schools • Auditoriums • Museums • Conferences • Tour Groups
Specifications:
Dimensions:
Weight:
Color:
Battery Type:
FCC ID:
Industry Canada Cert.:
Operating Freq.:
Intermediate Freq.:
FM Deviation:
De-Emphasis:
AFC Range:
Sensitivity:
Input Overload:
Frequency Response:
Signal-to-Noise Ratio:
Receive Antenna:
Audio Output:
Output Connector:
Earphone:
Warranty:
Notes
*Note: FCC rules limit the use of the 72–76 MHz band to hearing assistance for the handicapped
only. Other frequencies are available that do not have this use restriction.
NOTE: SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE!
©2005, Williams Sound Corp. MCAT 039A
Receiver, Model TGS R30
3 5/8" L x 2 3/8" W x 7/8" H
(92.1 mm x 60.3 mm x 22.2 mm)
4.6 oz (130 g) with batteries
Gray
Two (2) AA 1.5 V non-rechargeable Alkaline batteries (BAT 001),
14 mA nom. current drain, 80 hours approx. life (OR)
Two (2) AA 1.5 V NiMH rechargeable batteries (BAT 026),
14 mA nominal current drain, 50 hours per charge approx.,
recharges in 14–16 hours, uses CHG 1600 Charger or CHG 200 Charger
CNM R30
13601021234
Pre-Tuned, Adjustable, 72 MHz - 76 MHz *
75 kHz
75 kHz
75 µS
± 120 kHz
4 µV at 12 dB Sinad with squelch defeated
20 mV
100 – 10 kHz, ± 3 dB
50 dB at 10 µV
Integral with earphone/headphone cord
35 mW, max. at 16 Ω
3.5 mm mono phone jack
Earbud-type with foam cushion, 3.5 mm plug, 32 Ω
Five years, parts and labor.
90 days on cords, earphones, headphones,
batteries and other accessories.
The R30 Receiver can be field tuned to any of 10 wideband
channels using the PLT 005 Tuning Tool.
On/Off
Volume Switch
EAR Volume
1
Headphone "On" Indicator
Jack LED
TGS R30 Top
Williams Sound
®
Hearing Helper
TGS R30 Front
®
Williams Sound
Helping People Hear
