5.1 AC Power Cable

Types of AC Power Cables
AC power cables are classified into two types: C13 straight female to PI straight male AC power
cable and C13 straight female to C14 straight male AC power cable.
Appearance and Structure
Figure 5-1
Figure 5-1 Appearance of a C13 straight female to PI straight male AC power cable
female connector
Figure 5-2
Issue 16 (2015-08-26)
NOTE
The AC power cables delivered must comply with the standards used in the delivery destination. This
section uses the AC power cables complying with China's national standards as an example.
shows the appearance of a C13 straight female to PI straight male AC power cable.
C13 straight
shows the appearance of a C13 straight female to C14 straight male AC power cable.
