1.1 Components Available in V100R001C00

Available Models
Table 1-1
Table 1-1 Models available in V100R001C00
Series
CE6800
CE5800
Available Power Modules
Table 1-2
Table 1-2 Power modules available in V100R001C00
Power Module
Type
AC power module
Available Fan Modules
Table 1-3
Issue 16 (2015-08-26)
lists the switch models available in V100R001C00.
Model
CE6850-48S4Q-EI
CE6850-48T4Q-EI
CE5850-48T4S2Q-
EI
lists the power modules available in V100R001C00.
Power Module
PAC-150WA
PAC-350WA-B
PAC-350WA-F
lists the fan modules available in V100R001C00.
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1 Version Support for Components
Maximum Number of Ports Supported and Port
Description
52 total:
48 10GE SFP+ optical ports, 4 40GE QSFP+ optical
ports (can be split into four 10GE ports)
52 total:
48 10GBASE-T Ethernet electrical ports, 4 40GE
QSFP+ optical ports (can be split into four 10GE
ports)
54 total:
48 10/100/1000BASE-T Ethernet electrical ports, 4
10GE SFP+ optical ports, 2 40GE QSFP+ optical ports
(cannot be split into four 10GE ports)
Power Description
150 W AC power module
(natural heat dissipation)
350 W AC power module (air
exhaust on front panel)
350 W AC power module (air
intake on front panel)
