Related Manuals for MetalMaster SJ-24D
Summary of Contents for MetalMaster SJ-24D
- Page 1 Instructions Manual for SJ-24D (S641) 06/01/2020 BEAD ROLLER OPERATION MANUAL Model. SJ-24D Product Code S641 Edition No :MBR-001 Date of Issue :05/2019...
- Page 2 This manual is only for your reference. Owing to the continuous improvement of the Metalmaster machines, changes may be made at any time without obligation or notice. Please ensure the local voltage is the same as listed on the specification plate before operating any electric machine.
-
Page 3: Table Of Contents
Instructions Manual for SJ-24D (S641) 06/01/2020 OPERATION MANUAL C O N T E N T S: 1. GENERAL MACHINE INFORMATION 1.1 Specifications..............4 1.2 Packing Contents............4 2. IMPORTANT INFORMATION 2.1 Safety Requirements............ 5 2.2 Additional Safety For Bead Rolling Machine..7 3. -
Page 4: Specifications
Instructions Manual for SJ-24D (S641) 06/01/2020 OPERATION MANUAL 1.1 SPECIFICATIONS Product Code S641 Model SJ-24D Bead and Flange 1.2/18 Capacity (mm/gauge) Shear 1.0/20 Throat (mm) Bead Mandrels Sizes (mm//in) 6.35//1/4,9//3/8,12.7//1/2 Flange Mandrels Sizes (mm//in) 1.6//1/16,3//1/8,6.35//1/4 Shearing Mandrel Quantity 1 Set 1.2 PACKING CONTENTS... -
Page 5: Safety Requirements
Instructions Manual for SJ-24D (S641) 06/01/2020 OPERATION MANUAL 2.1 SAFETY REQUIREMENTS DO NOT use this machine unless you have read this manual or have been instructed in the use of this machine in its safe use and operation WARNING This manual provides safety instructions on the proper setup, operation, maintenance, and service of this machine. - Page 6 Instructions Manual for SJ-24D (S641) 06/01/2020 OPERATION MANUAL 2.1 SAFETY REQUIREMENTS Cont. WEARING PROPER APPAREL Do not wear FORCING MACHINERY. Do not force the ma- chine. It will do the job safer and better at the clothing, apparel or jewelry that can become entangled in moving parts.
-
Page 7: Additional Safety For Bead Rolling Machine
Instructions Manual for SJ-24D (S641) 06/01/2020 OPERATION MANUAL DO NOT use this machine unless you have read and understand the manual and the requirements for the safe operation of this machine. Safety glasses must be worn when Long and loose hair must be contained when operating this equipment. -
Page 8: Unpacking
Instructions Manual for SJ-24D (S641) 06/01/2020 OPERATION MANUAL 3.1 UNPACKING This machine was carefully packaged for safe transport. When unpacking, separate all enclosed items from packaging materials and inspect them for shipping damage. If items are damaged, please contact your distributor. -
Page 9: Alignment
Instructions Manual for SJ-24D (S641) 06/01/2020 OPERATION MANUAL 3.3 ALIGNMENT The Bead Roller usually does not need the operator to adjust the alignment. However, poor alignment will effect the quality of the metal forming and the ability of the machine to cut sheet metal. -
Page 10: Changing Dies
Instructions Manual for SJ-24D (S641) 06/01/2020 OPERATION MANUAL 3.4 CHANGING DIES The Bead Roller comes with a variety of bead and flange dies, as well as the cutting dies & plates. (assembled to the machine before shipping) Use the following instructions when you change dies. - Page 11 2. Using the handle, tighten 1 to 3 turns, depending on desired results. Metalmaster advises to turn the handle slowly as you work. A variety of metals and material gauge will produce a different result with the same dies and will require various degrees of effort.
-
Page 12: Operation
Instructions Manual for SJ-24D (S641) 06/01/2020 OPERATION MANUAL 4. OPERATION 4.1 GETTING STARTED • Loosen the Roller Tensioner Lever lock nut (Fig.10) • Loosen the Roller Tensioner Lever (39#) by turning the lever in a counter-clockwise direction. (Fig 9). Note: The through hole in the upper frame is slotted. The... -
Page 13: Forming Curves
Instructions Manual for SJ-24D (S641) 06/01/2020 OPERATION MANUAL 4.3 FORMING CURVES The success to forming curves with the bead roller is careful coordination between cranking the handle, and moving the metal workpiece slowly through the dies, while turning it through the curve, at the same time. -
Page 14: Spare Parts
Instructions Manual for SJ-24D (S641) 06/01/2020 OPERATION MANUAL SPARE PARTS SECTION The following section covers the spare parts diagrams and lists that were current at the time this manual was originally printed. Due to continuous improvements of the machine, changes may be made at any time without notification. - Page 15 Instructions Manual for SJ-24D (S641) 06/01/2020 OPERATION MANUAL SPARE PARTS DIAGRAM...
- Page 16 Instructions Manual for SJ-24D (S641) 06/01/2020 OPERATION MANUAL SPARE PARTS LIST Part No. Description Qty. Part No. Description Qty. Base 22-02 6mm Flange Die Roll Block 23-01 3mm Flange Die Driving Shaft 23-02 3mm Flange Die Driven Shaft 24-01 2mm Flange Die...
-
Page 17: Risk Assessment Sheets
Instructions Manual for SJ-24D (S641) 06/01/2020 General Machinery Safety Instructions Machinery House requires you to read this entire Manual before using this machine. 1. Read the entire Manual before starting 14. Use correct amperage extension cords. machinery. Machinery may cause serious injury if Undersized extension cords overheat and lose not correctly used. - Page 18 Instructions Manual for SJ-24D (S641) 06/01/2020 Swage & Jenny Machine Safety Instructions Machinery House requires you to read this entire Manual before using this machine. 1. Maintenance. 11. Work area hazards. Make sure the Swage & Jenny is Keep the area around the turned off and disconnect from the main power Swage &...
- Page 19 Instructions Manual for SJ-24D (S641) 06/01/2020...
