StarLeaf Pronto 210 Installation Manual

StarLeaf Pronto 210 Installation Guide
Before installing Pronto 210, read the safety and compliance information at:
support.starleaf.com/safety
All the components and cables you need for this installation are included in the box
Antenna
USB-A
Keypad
Pronto Cable USB
For more help with any StarLeaf product, go to: support.starleaf.com
Hub 20
USB-A HDMI Ethernet
Network
Room screen
1. Screw both antennas into
Hub 20 behind a room screen, make sure that there is
enough space
Antenna
2. Connect the network, room screen, and keypad to
Hub 20. Connect Pronto Cable USB to enable wired
sharing for your meeting room
3. Connect the power supply to
few minutes to initialize
4. Enter the QuickConnect code using the keypad. To
generate the QC code, admins must add
their StarLeaf Portal
5. When provisioning is complete, your room screen will
display the idle instructions screen until content is
presented
How To Generate A Quickconnect Code
1. Go to the Room Systems page on your Admin portal
and click Add room system
Power supply
2. Complete all required fields and ensure you select
StarLeaf Hub 20 in the Hardware endpoint section
3. Click Apply. The QC code appears in the Hardware
endpoint section

How to install Pronto 210

Hub 20. If you want to place
Hub 20. It may take a
Hub 20
Copyright © StarLeaf March 2020
