WHITE-RODGERS
Operator: Save these instructions for future use!
FAILURE TO READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY
BEFORE INSTALLING OR OPERATING THIS CONTROL COULD CAUSE
PERSONAL INJURY AND/OR PROPERTY DAMAGE.
This adaptor plate assembly is designed for mounting a
1F6X, 1F7X, or 1F9X series thermostat to the wall or to a
junction box. The wall cover plate covers the junction box,
wall damage, or old thermostat markings. The adaptor
plate is designed to allow horizontal thermostat mounting,
regardless of junction box orientation.
All kits may not have adaptor plate or all screws shown.
CAUTION
!
To prevent electrical shock and/or equip-
ment damage, disconnect electrical power
at main fuse or circuit breaker until installa-
tion is complete.
CONTENTS
Description ......................................................... 1
Precautions ........................................................ 1
Installation .......................................................... 2
For 1F9X Digital Thermostats
For 1F7X Quartz Clock Thermostats
For 1F6X Thermostats
WHITE-RODGERS DIVISION
EMERSON ELECTRIC CO.
9797 REAVIS ROAD
ST. LOUIS, MISSOURI 63123-5398
Adaptor Plate Assembly
INSTALLATION INSTRUCTIONS
Wall Cover
Plate
This instruction sheet is not intended as a wiring guide.
Refer to the thermostat installation instructions to ensure
proper wiring.
Printed in U.S.A.
F61 Series
DESCRIPTION
Adaptor Plate
No. 6 X 5
⁄
16 " Phillips
pan-head screw (2)
6-19 X 3
pan-head screw (3)
6-32 X 3
⁄
4 " flat-head
machine screw (4)
PRECAUTIONS
NOTE
PART NO. 37-5148B
Replaces 37-5148A
⁄
8 " Phillips
9607
Advertisement
Table of Contents
Related Manuals for White Rodgers 37-5148B
Summary of Contents for White Rodgers 37-5148B
-
Page 1: Installation Instructions
Adaptor Plate No. 6 X 5 ⁄ 16 ” Phillips pan-head screw (2) 6-19 X 3 ⁄ 8 ” Phillips pan-head screw (3) 6-32 X 3 ⁄ 4 ” flat-head machine screw (4) PRECAUTIONS PART NO. 37-5148B Replaces 37-5148A 9607... - Page 2 INSTALLATION FOR 1F9X DIGITAL THERMOSTATS No. 6 X ⁄ pan-head screws Thermostat Figure 1. Mounting 1F9X digital thermostat to horizontal junction box 6-32 X machine screws No. 6 X ⁄ ” Phillips pan-head screws Thermostat Figure 2. Mounting 1F9X digital thermostat to vertical junction box 6-32 X ⁄...
- Page 3 NOTE When installing wall cover plate and thermostat directly to wall, use the pointed screws supplied with the thermostat. No. 6 X 1” pan-head screws (supplied with thermostat) Thermostat Figure 3. Mounting 1F9X digital thermostat to wall FOR 1F7X QUARTZ CLOCK THERMOSTATS NOTE Do not install the wall mounting plate and subbase at the same time.
- Page 4 NOTE Do not install the wall mounting plate and subbase at the same time. The thermostat will not operate properly if both wall mounting plate and subbase are installed. 6-32 X ⁄ ” flat-head machine screws 6-32 X ⁄ ” flat-head machine screws Thermostat Figure 5.
- Page 5 FOR 1F6X THERMOSTATS 6-32 X ⁄ ” flat-head machine screws No. 6 X ⁄ ” Phillips pan-head screws In st ru ct io ns In si de C ov er Thermostat Cover Figure 7. Mounting 1F60 thermostat to horizontal junction box 6-32 X ⁄...
- Page 6 NOTE When installing wall cover plate and thermostat directly to wall, use the pointed screws supplied with the thermostat. No. 6 X 1” pan-head screws (supplied with thermostat) No. 6 X ⁄ ” Phillips pan-head screws In st ru ct io ns In si de C...
- Page 7 No. 6 X ⁄ ” Phillips pan-head screws T IM In st ru ct io n s In si d e C o ve L F U T IO X IL IA R F A N I T E Thermostat (connect harness –...
- Page 8 If you need further information about this product, please write to White-Rodgers Division, Emerson Electric Co. 9797 Reavis Road St. Louis, MO 63123-5398 Attention: Technical Service Department...
