Programmable electronic digital thermostat

Advertisement

Quick Links

WHITE-RODGERS
Operator: Save these instructions for future use!
FAILURE TO READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY
BEFORE INSTALLING OR OPERATING THIS CONTROL COULD CAUSE
PERSONAL INJURY AND/OR PROPERTY DAMAGE.
Your new White-Rodgers 5-Day/2-Day Digital Thermostat uses
the technology of a solid-state microcomputer to provide precise
time/temperature control. This thermostat offers you the flexibil-
ity to design heating and cooling programs that fit your needs.
Features:
• Battery powered (3 "AA" Energizer
cluded).
• Separate 5-day (weekday) and 2-day (weekend) programming
• Simultaneous heat and cool program storage
• Preprogrammed temperature control
• Four separate time/temperature settings per 24-hour period
This thermostat is intended for use with a low voltage system; do
not use this thermostat with a line voltage system. If in doubt
about whether your wiring is millivolt, line, or low voltage, have
it inspected by a qualified heating and air conditioning contractor
or licensed electrician.
Do not exceed the specification ratings.
All wiring must conform to local and national electrical codes and
ordinances.
This control is a precision instrument, and should be handled
carefully. Rough handling or distorting components could cause
the control to malfunction.
ELECTRICAL DATA
Electrical Rating:
8 to 30 VAC 50/60 Hz. or D.C.
0.05 to 1.5 Amps (Load per terminal)
1.5 Amps Maximum Total Load (All terminals combined)
THERMAL DATA
Setpoint Temperature Range:
45 F to 90 F (7 C to 32 C)
Operating Ambient Temperature Range:
32 F to 105 F
Operating Humidity Range:
0 to 90% RH (non-condensing)
Shipping Temperature Range:
-40 F to 150 F
WHITE-RODGERS DIVISION
EMERSON ELECTRIC CO.
9797 REAVIS ROAD
ST. LOUIS, MISSOURI 63123-5398
R
• LCD continuously displays set point, and alternately dis-
• Temperature override until next program period
• Manual program override (HOLD temperature)
• User may select either 12- or 24-hour clock display
®
alkaline batteries in-
• Temperature range 45 to 90 F
• Standard five terminals for single or two-transformer sys-
• B and O terminals for single stage heat pumps or damper
To prevent electrical shock and/or equipment dam-
age, disconnect electric power to system at main fuse
or circuit breaker box until installation is complete.
Do not use on circuits exceeding specified voltage.
Higher voltage will damage control and could cause
shock or fire hazard.
Do not short out terminals on gas valve or primary
control to test. Short or incorrect wiring will damage
thermostat and could cause personal injury and/or
property damage.

APPLICATIONS

For use with:
DO NOT USE WITH:
Printed in U.S.A.
1F80-41
Programmable Electronic Digital Thermostat
INSTALLATION AND
OPERATION INSTRUCTIONS
plays time and room temperature
F/ C convertibility
tems
operation
CAUTION
!
WARNING
!
Standard heat/cool or heat only systems
Electric heat systems
Gas or oil fired systems
Gas systems with intermittent ignition devices (I.I.D)
and/or vent dampers
Hydronic (hot water or steam) systems
Single-stage heat pump systems
Millivolt systems
Multi-stage systems
Systems exceeding 30 VAC and 1.5 amps
3-wire zoned hydronic heating systems

DESCRIPTION

PRECAUTIONS

SPECIFICATIONS

PART NO. 37-5604B
Replaces 37-5604A
9602

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1F80-41 and is the answer not in the manual?

Questions and answers

Summary of Contents for White Rodgers 1F80-41

  • Page 1: Specifications

    Millivolt systems DO NOT USE WITH: • Multi-stage systems • Systems exceeding 30 VAC and 1.5 amps • 3-wire zoned hydronic heating systems Printed in U.S.A. 1F80-41 INSTALLATION AND OPERATION INSTRUCTIONS DESCRIPTION PRECAUTIONS CAUTION WARNING SPECIFICATIONS PART NO. 37-5604B Replaces 37-5604A...
  • Page 2: Remove Old Thermostat

    INSTALLATION REMOVE OLD THERMOSTAT 1. Shut off electricity at the main fuse box until installation is complete. Ensure that electrical power is disconnected. 2. Remove the front cover of the old thermostat. With wires still attached, remove wall plate from the wall. If the old thermostat has a wall mounting plate, remove the thermostat and the wall mounting plate as an assembly.
  • Page 3 Heating System Figure 3. Typical wiring diagram for heating only, 2-wire, single transformer systems or millivolt systems NOTE Thermostat Jumper wire must be added between R and B terminals on the primary control (jumper wire not provided with thermostat. Add jumper wire (not provided with thermostat) Figure 4.
  • Page 4 CHECK THERMOSTAT OPERATION If at any time during testing your system does not operate properly, contact a qualified serviceperson. Fan Operation If your system does not have a G terminal connection, skip to Heating System. 1. Turn on power to the system. 2.
  • Page 5: Programming Your Thermostat

    OPERATING FEATURES Now that you are familiar with the thermostat buttons and display, read the following information to learn about the many features of the thermostat. • SIMULTANEOUS HEATING/COOLING PROGRAM STORAGE — When programming, you can enter both your heating and cooling programs at the same time. There is no need to reprogram the thermostat at the beginning of each season.
  • Page 6 during each period. You may also want to look at the sample program table to get an idea of how the thermostat can be programmed. Entering Your Program Follow these steps to enter the heating and cooling programs you have selected. NOTE The thermostat should be programmed in the 12-hour format, then switched to the 24-hour format, if desired (see OPERAT-...
