Summary of Contents for XL displays XC 3
- Page 1 XD 7 Roof Standard Wall Window Wall Tunnel Part Entrance Wall XD 6 Tubes XD 5 Canopy Banner Lighting Kit Canopy XC 3 XD 4 Stool XC 3 Ballast Standard Wall Barrel Window Wall Entrance Wall Wall Ballast Tube Ballast...
- Page 2 1. TECHNICAL DATA Tube diameter XC 3 XD 4 XD 5 XD 6 Exterior side length 3,0 m 4,0 m 5,0 m 6,0 m Entrance height 1,95 m 2,0 m 2,5 m 3,0 m Total height 2,6 m 2,38 m...
- Page 3 2. CONTENTS OF DELIVERY XC 3 1x Anchoring line set (1) 1x Repair kit (2) 1x Hand pump (3) 1x User manual and quick user guide (4) 1x Allen key (5) XD 4 1x Anchoring webbing set (1) 3x Repair kit (2)
- Page 4 3.2.1. INFLATION XD 4 5 6 7 To inflate the tent, the valve housing, which can be XD 4 5 6 7 XC 3 found on the inner side of each tube, must be screwed firmly into the socket. A backflow preventer (red button) in the valve housing prevents the air from escaping again.
- Page 5 To deflate, unscrew the entire valve housing from the socket.. 3.2.3 OVERPRESSURE VALVE XC 3 XD 4 5 6 7 On each tube there is a red overpressure valve that automatically opens as soon as the maximum air...
- Page 6 Sand or dirt can jam the spring and valve, which may prevent the valve from functioning correctly. 3.2.4 RAISING XC 3 XD 4 5 6 7 PLEASE NOTE: Raising the tent from the ground requires some assistance. Before the tubes are fully inflated, the middle of the tent —...
