White Rodgers 1F78H Installation Instructions Manual

Installation Instructions for
Heating & Air Conditioning
5/2 Day Programmable Thermostat
YOUR THERMOSTAT REPLACES
Typical System Compatibility Chart
Standard Heat Only Gas or Oil Fired Systems (24 volt)*
Electronic Ignition Heat Only Two Wire Systems (24 volt)*
Electronic Ignition Heat Only Gas or Oil Fired Systems (24 volt)*
Standard Heat/Cool Systems (24 volt)*
Heat/Cool Systems Electric Heat (24 volt)*
Heat Only Electric Heat Systems (24 volt)*
Cool Only Systems (24 volt)*
Heat Pump Systems (No Aux or Emergency Heat)*
Hot Water Zone Heat Only Systems
Hot Water Zone Heat Only (Three Wire) Systems
Line Voltage Heating or Baseboard 110/240 Volt Systems
Millivolt Systems Floor or Wall Furnaces
12 VDC Mobile Home Application
Multistage Systems
Systems Exceeding 30VAC, 1.5 Amp
* Requires common wire for 24VAC at the thermostat
2
THERMOSTAT DETAILS
Mounting
hole
W904
W905
W905
Clip for
Hydronic
System
W904
Clip for
Celsius Display
Figure 1. Thermostat base
WHITE-RODGERS
EMERSON ELECTRIC CO.
9797 REAVIS ROAD
ST. LOUIS, MISSOURI 63123-5398
www.white-rodgers.com
1F78H
1F78H
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
No
No
No
No
No
Mounting
W B RC
RH
C G O
ELEC GAS
Electric/Gas
Switch
CONTENTS
Preparations .................................................. 1
Thermostat Details ........................................ 1

Removing Old Thermostat ............................ 1

Mounting and Wiring ..................................... 2
Check Thermostat Operation ........................ 3
Configuration Menu ....................................... 4
Programming your Thermostat ..................... 5
Specifications ................................................ 7
Troubleshooting ............................................ 8
1
PREPARATIONS
Assemble tools required as shown below.
HAND OR POWER
DRILL WITH 3/16 INCH
DRILL BIT, IF NEEDED
Failure to follow and read all instructions carefully
before installing or operating this control could cause
personal injury and/or property damage
3
REMOVING OLD THERMOSTAT
hole
To prevent electrical shock and/or equipment damage,
disconnect electrical power to the system at the main
fuse or circuit breaker until installation is complete.
Before removing wires from old thermostat's switching subbase,
label each wire with the terminal designation it was removed from.
1. Remove Old Thermostat: A standard heat/cool thermostat
consists of three basic parts:
a. The cover, which may be either a snap-on or hinge type.
Y
b. The base, which is removed by loosening all captive screws.
c. The switching subbase, which is removed by unscrewing
the mounting screws that hold it on the wall or adaptor plate.
2. Shut off electricity at the main fuse box until installation is
complete. Ensure that electrical power is disconnected.
3. Remove the front cover of the old thermostat. With wires still
attached, remove wall plate from the wall. If the old thermostat
has a wall mounting plate, remove the thermostat and the wall
mounting plate as an assembly.
4. Identify each wire attached to the old thermostat.
5. Disconnect the wires from the old thermostat one at a time.
DO NOT LET WIRES FALL BACK INTO THE WALL.
6. Install new thermostat using the following procedures.
Printed in U.S.A.
FLAT BLADE SCREWDRIVER
WIRE CUTTER/STRIPPER
SPIRIT LEVEL OR PLUMB BOB AND LINE OPTIONAL—
THERMOSTAT DOES NOT NEED TO BE LEVEL TO WORK PROPERLY
CAUTION
!
PART NO. 37-6448A
0247
