White Outdoor L-Syle Operator's Manual
White Outdoor L-Syle Operator's Manual

White Outdoor L-Syle Operator's Manual

Two-stage snow thrower

Advertisement

Safety • Assembly • Operation • Tips & Techniques • Maintenance • Troubleshooting • Parts Lists • Warranty
OPERATOR'S MANUAL
Two-Stage Snow Thrower — L-Style
IMPORTANT
READ SAFETY RULES AND INSTRUCTIONS CAREFULLY BEFORE OPERATION
Warning: This unit is equipped with an internal combustion engine and should not be used on or near any uniiproved forest-covered, brush-
covered or grass-covered land unless the engine's exhaust system is equipped with a spark arrester meeting applicable local or state laws (if any).
If a spark arrester is used, it should be maintained in effective working order by the operator. In the State of California the above is required by law
(Section 4442 of the California Public Resources Code). Other states may have similar laws. Federal laws apply on federal lands. A spark arrester
for the muffler is available through your nearest engine authorized service dealer or contact the service department, P.O. Box 361131 Cleveland,
Ohio 44136-0019.
PRINTED IN U.S.A
FORM NO. 769-01877A
MTD LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
06/28/2005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L-Syle and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for White Outdoor L-Syle

  • Page 1 Safety • Assembly • Operation • Tips & Techniques • Maintenance • Troubleshooting • Parts Lists • Warranty OPERATOR’S MANUAL Two-Stage Snow Thrower — L-Style IMPORTANT READ SAFETY RULES AND INSTRUCTIONS CAREFULLY BEFORE OPERATION Warning: This unit is equipped with an internal combustion engine and should not be used on or near any uniiproved forest-covered, brush- covered or grass-covered land unless the engine’s exhaust system is equipped with a spark arrester meeting applicable local or state laws (if any).
  • Page 2: Table Of Contents

    If you have difficulty assembling this product or have any questions regarding the controls, operation, or maintenance of this unit, you can seek help from the experts. To reach a local White Outdoor dealer or retailer, visit www.whiteoutdoor.com or or phone our Dealer Locator line at (800)-949-4483.
  • Page 3: Safety Labels

    ������ �� ���� ���� ���� �������� �������� ��� ������ ������� ���� �������� �� ����� ��� �������� ����� ��� ����� ��� ��������� ���� �� ������ �� ��������� ������ ��������� ������ ������� ���� ������� �� ��� ������ ������ ������� ����� ��� ������ ����� ���� ������� ������ ����������...
  • Page 4: Safe Operation Practices

    DANGER: This machine was built to be operated according to the rules for safe operation in this manual. As with any type of power equipment, carelessness or error on the part of the operator can Safe result in serious injury. This machine is capable of amputating hands and feet and throwing objects. Failure to observe the following safety instructions could result in serious injury or death.
  • Page 5: Maintenance And Storage

    (e.g. wheel weights, tire chains, cabs etc.). 20. If situations occur which are not covered in this manual, use care and good judgment. Contact your White Outdoor dealer or call (800) 949-4483 for the name of your nearest servicing dealer.
  • Page 6: Setting Up Your Snow Thrower

    Setting Up Your Snow Thrower � NOTE: All references in this manual to the left or right side of the snow thrower is from the operating position only. Exceptions, if any, will be specified. IMPORTANT This unit is shipped with the engine full of oil.
  • Page 7: Tire Pressure

    Shear Pin Storage An area for convenient shear pin storage is located under the plastic dash panel. See Figure 6. Chute Clean-Out Tool The clean-out tool is conveniently fastened to the rear of the auger housing with a mounting clip. See Figure 10. 1.
  • Page 8: Operating Your Snow Thrower

    Operating Your Snow ����� �������� Thrower ����� ��� WARNING Read, understand, ������ and follow all instruc- tions and warnings on the machine and in this manual before operating. Now that you have set up your snow thrower for Use extreme care operation, get acquainted with its controls and when handling features.
  • Page 9: Chute Assembly

    Auger Control ����� ������� �� The auger control is located on the left handle. Squeeze the control grip against the handle to engage the augers and start snow throwing action. Release to stop. Drive Control ����� ������� �� The drive control is located on the right handle. Squeeze the control grip against the handle to engage the wheel drive.
  • Page 10: Starting The Engine

    Service the engine with gasoline and oil as instructed in the Tecumseh Engines manual packed separately with your snow thrower. Read instructions carefully. 1. Attach spark plug wire to spark plug. Make certain the WARNING metal loop on the end of the spark plug wire (inside the rubber boot) is fastened securely over the metal tip on the spark plug.
  • Page 11 6. Wipe all snow and moisture from the area around the engine as well as the area in and around the drive control and auger control. Also, engage and release both controls several times. NOTE: Keep the key in a safe place. The engine cannot start without the ignition key.
  • Page 12: Making Adjustments

    Making Adjustments WARNING Read, understand, and follow all instruc- tions and warnings on the machine and in this manual before operating. Never attempt to make any adjust- ments while the engine is running, except where speci- fied in operator’s manual. Auger Control To adjust the auger control, refer to page 13.
  • Page 13: Drive Control

    Drive Control When the drive control is released and in the disengaged “up” position, the cable should have very little slack. It should NOT be tight. Check the adjustment of the drive control as follows: 1. With the drive control released, push the snow thrower gently forward.
  • Page 14: Maintenance

    Engine Refer to the separate Tecumseh Engines manual packed with your unit for all engine maintenance. Lubrication Engine Maintaining Refer to the separate Tecumseh Engines manual packed with your unit for all engine lubrication instruc- Your Snow tions. Gear Shaft Thrower The gear (hex) shaft should be lubricated at least once a season or after every 25 hours of operation.
  • Page 15: Auger Belt Replacement

    � � Auger Belt Replacement To remove and replace your snow thrower’s auger belt, proceed as follows: 1. Remove the plastic belt cover on the front of the engine by removing the two self-tapping screws. NOTE: Drain the gasoline from the snow thrower, or place a piece of plastic under the gas cap.
  • Page 16: Drive Belt Replacement

    Maintaining Your Snow Thrower NEVER replace the auger shear pins with anything other than OEM Part No.738-04124A replacement shear pins. Any damage to the auger gearbox or other components as a result of failing to do so will NOT be covered by your snow thrower’s warranty.
  • Page 17: Friction Wheel Removal

    Friction Wheel Removal If the snow thrower fails to drive with the drive control engaged, and performing the drive control cable adjust- ment on page 14 fails to correct the problem, the friction wheel may need to be replaced. Follow the instructions below.
  • Page 18: Off-Season Storage

    If the snow thrower will not be used for 30 days or longer, or if it is the end of the snow season when the last pos- sibility of snow is gone, the equipment needs to be stored properly. Follow storage instructions below to ensure top performance from the snow thrower for many more years.
  • Page 19: Troubleshooting

    1. Move choke lever to OFF position. 2. Clean fuel line; fill tank with clean, fresh gasoline. 3. Drain fuel tank. Refill with fresh fuel. 4. Contact White Outdoor Service Center. 1. Contact White Outdoor Service Center. 1. Stop engine immediately and disconnect spark plug wire.
  • Page 20 Style L �� �� � �� �� �� �� �� � �� � �� � � � � � � �� �� �� �� �� �� �� �� �� �� �� �� � �� �� � � �� �� � ��...
  • Page 21 731-2635 Snow Removal Tool Mount 684-04057 Impeller Assembly, 12” Dia. 710-0347 Hex Screw, 3/8-16, 1.75, Gr5 710-0451 Bolt, Carriage, 5/16-18, .750 Gr1 710-0604A Screw, 5/16-18, 0.625 710-0703 Screw, Carriage, 1/4-20, .750, Gr5 712-04063 Nut, Flange Lock, 5/16-18, Nylon 712-04064 Nut, Flange Lock, 1/4-20, Nylon 712-04065 Nut, Flange Lock, 3/8-16, Nylon 10.
  • Page 22 Style L �� �� �� �� �� �� � �� �� � �� �� �� �� �� �� �� �� �� � �� �� �� �� �� �� �� � � �� � � � �� � �� �� �� ��...
  • Page 23: Illustrated Parts List

    684-04109A Handle Engagement Assembly RH 738-04194 Flange Shoulder Screw 731-04894A Lock Plate 711-04287 Pivot Rod 735-0199A Rubber Bumper 710-04354 Screw, 1/4-20 x.375 731-04896A Clutch Lock Cam 712-04081A Shoulder Nut, 1/4-20 725-04214 Wire Harness (Not Shown) 10. 725-1649 Light Socket 11. 720-0274 Handle Grip 12.
  • Page 24 Style L �� �� �� �� �� �� �� �� �� �� � �� �� �� � � � � �� �� �� � � �� �� �� �� �� �� �� �� �� �� � �� �� �� �� ��...
  • Page 25 756-04177 Disc, Friction Wheel 684-04153 Friction Wheel Assembly, 5.5 OD 684-04154 Support Bracket, Friction Wheel 684-04156 Shift Assembly, Rod 710-0627 Hex Screw, 5/16-24, .750, Gr5 710-0788 Screw, 1/4-20, 1.000 710-0896 Screw, 1/4-14 x .625 712-04065 Nut, Flange Lock, 3/8-16, Nylon 712-0413 Nut, Jam Lock, 5/8-18, Gr5, Nylon 10.
  • Page 26 NOTES...
  • Page 27 NOTES...
  • Page 28: Warranty

    MANUFACTURER’S LIMITED WARRANTY FOR The limited warranty set forth below is given by MTD LLC with respect to new merchandise purchased and used in the United States, its posses- sions and territories. “MTD” warrants this product against defects in material and workmanship for a period of two (2) years commencing on the date of original purchase and will, at its option, repair or replace, free of charge, any part found to be defective in materials or workmanship.
