OPERATOR'S MANUAL
IMPORTANT: READ SAFETY RULES AND INSTRUCTIONS CAREFULLY
Warning:
This unit is equipped with an internal combustion engine and should not be used on or near any unimproved forest-
covered, brush-covered or grass-covered land unless the engine's exhaust system is equipped with a spark arrester meeting
applicable local or state laws (if any). If a spark arrester is used, it should be maintained in effective working order by the operator.
In the State of California the above is required by law (Section 4442 of the California Public Resources Code). Other states may have
similar laws. Federal laws apply on federal lands. A spark arrester for the muffler is available through your nearest engine authorized
service dealer or contact the service department, P.O. Box 361131 Cleveland, Ohio 44136-9722.
WHITE OUTDOOR PRODUCTS COMPANY P.O. BOX 361131 CLEVELAND, OHIO 44136-9722
PRINTED IN U.S.A.
Zero Turn Tractor
Models
ZT-1850, ZT-2150, &
ZT-2250
FORM NO.
770-10104E.fm
(10/00)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZT-1850, ZT-2150, ZT-2250 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for White Outdoor ZT-1850, ZT-2150, ZT-2250

Summary of Contents for White Outdoor ZT-1850, ZT-2150, ZT-2250

  • Page 1 Federal laws apply on federal lands. A spark arrester for the muffler is available through your nearest engine authorized service dealer or contact the service department, P.O. Box 361131 Cleveland, Ohio 44136-9722. WHITE OUTDOOR PRODUCTS COMPANY P.O. BOX 361131 CLEVELAND, OHIO 44136-9722 PRINTED IN U.S.A.

  • Page 2: Table Of Contents

    For future reference, please copy the model number and the serial number of the equipment in the space below. (Model Number) (Serial Number) WHITE OUTDOOR PRODUCTS COMPANY P.O. BOX 361131 CLEVELAND, OHIO 44136 CALLING CUSTOMER SUPPORT If you have difficulty assembling this product or have any questions regarding the controls, operation or maintenance of this unit, please call the Customer Dealer Referral Line.

  • Page 3: General Operation

    SECTION 1: MAINTAINING SAFETY WARNING: This symbol points out important safety instructions which, if not followed, could endanger the personal safety and/or property of yourself and others. Read and follow all instructions in this manual before attempting to operate this machine. Failure to comply with these instructions may result in personal injury.

  • Page 4: Slope Operation

    23. Muffler and engine become hot and can cause a burn. Do not touch. 24. Check overhead clearances carefully before driving under low hanging tree branches, wires, door openings etc., where the operator may be struck or pulled from the unit, which could result in serious injury.
  • Page 5 Service Safe Handling Of Gasoline: 1. To avoid personal injury or property damage use extreme care in handling gasoline. Gasoline is extremely flammable and the vapors are explosive. Serious personal injury can occur when gasoline is spilled on yourself or your clothes which can ignite. Wash your skin and change clothes immediately.

  • Page 6: Slope Gauge

    TO REDUCE THE RISK OF INJURY, DO NOT OPERATE MOWER UNLESS DISCHARGE CHUTE COVER OR GRASS CATCHER IS IN ITS PROPER PLACE. SECTION 2: SLOPE GAUGE Use this page as a guide to determine slopes where you may not operate safely. Do not operate your lawn mower on such slopes.

  • Page 7: Know Your Z-Series

    SECTION 3: KNOW YOUR Z-SERIES NOTE: Reference to right or left hand side of the mower is observed from the operating position. Throttle Lever And Choke Lever Lift Handle Read this operator’s manual and safety rules before operating your Z-Series. Compare the illustrations in this manual with your unit to familiarize yourself with the location of various controls and adjustments.

  • Page 8: Lift Handle

    Electric PTO (Power Take-Off) Knob The PTO switch is located on the right control panel and it is used to control the engagement of the cutting blades. When the knob is up, the cutting blades are engaged. When the knob is down, the cutting blades are disengaged.

  • Page 9: Parking Brake Pedal

    • Battery: The BATTERY indicator light will illuminate any time the ignition key is in the ON position and the engine is not running. If it illuminates while the engine is running, then the battery is in need of a charge. Refer to the MAINTENANCE section of this manual for the proper battery charging procedure.

  • Page 10: Operating Your Z-Series

    SECTION 4: OPERATING YOUR Z-SERIES Gas and Oil Fill-Up Service the engine with gasoline and oil as instructed in the separate engine manual packed with your mower. Read instructions carefully. Your unit is shipped with oil; however, you IMPORTANT: MUST check the oil level before operating. Be careful not to overfill.

  • Page 11: Quick Reference Chart

    • If safe for operation, walk the slope and look for hazards such as rocks, mounds, ruts, stumps, or other irregularities. • After removing debris and identifying irregularities of the slope, back the Z-Series up the steepest slope you intend to work. If it cannot negotiate the slope in reverse, the slope is too steep.

  • Page 12: Making Adjustments

    Release Handles = Neutral / Stop Full Right Forward And Full Left Back = Zero Turn Left Right Forward And Left Neutral = Left Turn SECTION 5: MAKING ADJUSTMENTS Adjusting the Mower Deck Height • To push or pull the lift lever, depress and hold the button.

  • Page 13: Steering Adjustment

    Checking the Brake Adjustment • Position the Z-Series on a level surface and move the throttle lever to the slowest position (turtle). • Stop the engine, remove the key from the ignition, and engage the parking brake. • Release both hydraulic relief levers. •...

  • Page 14: Maintaining Your Z-Series

    • Remove bolts that secure linkage to upper control handles and lower control arms. The shock absorbers should remain connected to linkage. See Figure 12. Hex Bolt Jam Nuts Hex Bolt Figure 12 • Insert quarter inch by seven inch pin or equivalent through the top and bottom alignment holes of the control arms to secure arms at positive neutral.

  • Page 15: Fuel Tank

    Deck Lift Pivot Grease Fittings Lift Handle Grease Fitting Control Tower Grease Fittings Engine Refer to the separate engine manual for engine maintenance instructions. Service air cleaner every 25 hours under normal conditions. Clean every few hours under extremely dusty conditions. To service the air cleaner, refer to the separate engine manual.

  • Page 16: Checking Hydraulic Oil

    Checking Hydraulic Oil Check the oil level of hydraulic units only when the engine is OFF. During initial break-in (first five hours of operation), check oil before each use and after every hour of operation. During normal operation, check oil after 50 hours of operation.

  • Page 17: Removing The Drive Belt

    • Slide the boot cover all the way up (toward the drive handles) to access the drive handle bolts. • Remove drive handle bolts, drive handles, and rubber boot. • Remove the four bolts securing the retaining plate to the control tower cover. •...

  • Page 18: Installing Drive Belt

    • Carefully pull the belt up and over the right hydrostatic cooling fan and then lift up and over the left hydrostatic cooling fan. • Pull the drive belt out of the unit. Installing Drive Belt • Set the parking brake and insert drive belt up and over the left and right hydostatic cooling fans.

  • Page 19: Removing The Mower Deck

    Front Lift Rods Figure 21 Removing The Mower Deck WARNING: Do not remove deck immedi- ately after operating the tractor. Allow the engine and other moving parts ample time to cool down. • Position the Z-Series on a hard flat surface and engage the parking brake.

  • Page 20: Installing The Mower Deck

    44” Deck 48” & 54” Deck Figure 25 Installing Mower Deck Belt • Remove the mower deck and the old mower deck drive belt from the mower deck. • Install and route the new belt according to the routing diagram. See Figure 26 or Figure 27. •...

  • Page 21: Mower Blades

    Mower Blades WARNING: The mower blades are sharp and can cause severe injury. Always protect hands by wearing heavy leather work gloves to grasp blades. Block Of Wood Blade Figure 29 SECTION 8: TROUBLESHOOTING Trouble Possible Cause(s) Engine fails to start PTO switch engaged.

  • Page 22: Parts List

    Models ZT-1850, ZT-2150, & ZT-2250 25 26...
  • Page 23 Models ZT-1850, ZT-2150, & ZT-2250 REF. PART DESCRIPTION 731-3263 Control Handle 712-3004A Flange Lock Nut 5/16-18 710-0451 Carriage Bolt 5/16-18 731-3185 Bellow 735-0251 Foot Pad 710-0642 Hex Washer Screw 1/4-20 x .75 703-2648 Bellow Retainer Bracket 712-0431 Flange Lock Nut 3/8-16 703-2807B Foot Pad Mounting Bracket 710-3168...
  • Page 24 Models ZT-1850, ZT-2150, & ZT-2250 13 14...
  • Page 25 Models ZT-1850, ZT-2150, & 2250 REF. PART DESCRIPTION 603-0649 Parking Brake Shift Ass’y 714-3004 Cotter Pin 710-3178 Carriage Bolt 3/8-16 x .75 741-0324 Hex Flange Bearing .506 ID x .590 703-3400 Brake Mounting Bracket 747-3404 Connecting Brake Rod 714-0104 Cotter Pin 710-0134 Carriage Screw 1/4-20 x .62 712-3027...
  • Page 26 Models ZT-1850, ZT-2150, & ZT-2250...
  • Page 27 Models ZT-1850, ZT-2150, & ZT-2250 REF. PART 603-0340 Bellcrank Ass’y Upper LH 603-0341 Bellcrank Ass’y Upper RH 603-0342 Bellcrank Ass’y Lower LH 603-0343 Bellcrank Ass’y Lower RH 603-0647 Support Ass’y Tower 603-0410 Rod Ass’y Control RH 603-0411 Rod Ass’y Control LH 710-0216 Hex Cap Screw 3/8-16 x .75 710-3005...
  • Page 28 Models ZT-1850, ZT-2150, & ZT-2250...
  • Page 29 Models ZT-1850, ZT-2150, & ZT-2250 REF. PART DESCRIPTION 737-3069 Pipe Plug 737-3070A Pipe Dipstick 603-0639 Hydraulic Tank Assembly 727-3116 Connection Fitting 721-0223 Seal 738-0940 Drain Plug 727-3120 Inlet Tube LH 727-3155 Tee Fitting 727-3154 Outlet Hose RH 727-3121 Inlet Tube RH 727-3153 Outlet Hose LH 710-0216...
  • Page 30 Models ZT-1850, ZT-2150, ZT-2250 REF. PART DESCRIPTION 618-3110A Drive Ass’y Complete 712-3004A Hex Flange Lock Nut 5/16-18 715-0136 Spiral Pin 3/16 x 1.25 717-3396 Spur Gear 14T 717-3455 Hydro Transmission 718-3053 Parking Brake Lever 721-0343 O-Ring 2.0 Dia. 727-3125 Cap Nut 3/8...
  • Page 31 Models ZT-1850, ZT-2150, ZT-2250 REF. PART 618-3110A Drive Ass’y Complete 611-3012 Axle Assembly 710-0852 Ribbed Neck Stud 618-3106 Carrier Assembly, Output 618-3107 Gear Assembly, 51T Internal & 20T 618-3109 Housing Ass’y 710-1342 Hex Washer Screw 1/4-20 x 1-1/8 711-1048 Brake Shaft...
  • Page 32 Model ZT-1850...
  • Page 33 Model ZT-1850 REF. PART 710-1314 Cap Screw 5/16-18 736-0119 Lock Washer 5/16 751-0619 Exhaust Pipe 710-0642 Hex Washer Screw 1/4-20 x .75 721-0208 Exhaust Gasket 710-3178 Carriage Bolt 3/8-16 x .75 751-3140 Oil Drain 751-3142 Oil Drain Cap 751B213146 Throttle Clamp 710-1237 Hex Washer Screw #10-32 x .625 703-3004...
  • Page 34 Models ZT-2150 & ZT-2250...
  • Page 35 Model ZT-2150 & ZT-2250 REF. PART DESCRIPTION 710-3009 Screw #10-24 x .750 746-3070 Throttle Cable Control 40.5” 746-3069 Choke Cable Control 52.0” 712-0161 Nylon Lock Nut #10-24 751-3141 Oil Drain Hose 751-3142 Oil Drain Cap 751-3140 Oil Drain 751-0535 Fuel Line Hose 726-0205 Hose Clamp 710-0751...
  • Page 36 Models ZT-1850, ZT-2150, & ZT-2250...
  • Page 37 Models ZT-1850, ZT-2150, & ZT-2250 REF. PART DESCRIPTION 629-3070 Wire Harness, Main - Not Shown 723-0455 Foam Protector, Indicator Light 710-3013 Hex Cap Screw 1/4-20 x .50 703-2809 Bracket, Indicator Bulb Mtg. 712-3027 Nut, Hex Flange Lock, 1/4-20 725-1718 Relay 703-2836 Bracket, Headlight Mtg.
  • Page 38 Models ZT-1850, ZT-2150, & ZT-2250...
  • Page 39 Models ZT-1850, ZT-2150, & ZT-2250 REF. PART DESCRIPTION 757-0375B Seat Ass’y 757-3009 Seat Arm Ass’y (If Equipped) 731-3154 Seat Slide 710-1260A Hex Washer Screw 5/16-18 x .750 738-0372 Shoulder Spacer 720-0190 Height Adjuster Knob 732-3098 Spring Index 712-3004A Flange Lock Nut 5/16-18 603-0294 Seat Base Bracket Ass’y 710-0788...
  • Page 40 Models ZT-1850, ZT-2150, & ZT-2250...
  • Page 41 Models ZT-1850, ZT-2150, & ZT-2250 REF. PART DESCRIPTION 711-0642A Handle Button 731-3158 Handle Deck Lift Grip 732-3097 Compression Spring 747-3405 Front Lift Rod 738-0507B Shoulder Screw .500 Dia x .434 710-0216 Hex Cap Screw 3/8-16 x .75 603-0422 Shaft Mounting Bracket - LH 603-0370 Pivot Link Bearing Ass’y 603-0313...
  • Page 42 Models ZT-1850, ZT-2150, & ZT-2250 REF. PART 712-3075 Hex Lock Nut, 1.0-14 736-0274 Flat Washer 603-0389A Pin Ass’y, Pivot 737-3090 Adapter, 1/8 NPTF x 1/8 NPTF 737-3072 Grease Fitting, 65° w/Extension 712-0431 Hex Flange Lock Nut, 3/8-16 712-0229 Push Nut, 3/8 ID 710-3178 Carriage Bolt, 3/8-16 x .75 710-0514...
  • Page 43 Model ZT-1850 REF. PART DESCRIPTION 712-0251 Retainer Nut 3/8-16 603-0720B Frame Assembly 712-0455 Retainer Nut 3/8-16 712-0431 Flange Lock Nut 3/8-16 710-0216 Hex Cap Screw 3/8-16 x .75 710-3144 Hex Cap Screw 3/8-16 x 2.0 712-3004A Flange Lock Nut 5/16-18 736-0258 Flat Washer .385 x 1.0 x .135 749-3087...
  • Page 44 Models ZT-2150 & ZT-2250 REF. PART 712-0251 Retainer Nut 3/8-16 603-0720B Frame Assembly 712-0455 Retainer Nut 3/8-16 712-0431 Flange Lock Nut 3/8-16 710-0216 Hex Cap Screw 3/8-16 x .75 710-3144 Hex Cap Screw 3/8-16 x 2.0 712-3004A Flange Lock Nut 5/16-18 736-0258 Flat Washer .385 x 1.0 x .135 749-3062...
  • Page 45 Models ZT-1850, ZT-2150, ZT-2250 REF. 722-0265 710-1260A 736-0231 651-3004 703-3490 712-0431 710-0216 734-1596 734-3163 634-3005 634-3030 734-0255 634-3050 634-3051 634-3052 PART DESCRIPTION Foam 2.04 x 3.50 x .62 Hex Washer Screw 5/16-18 x .75 Flat Washer .344 ID x 1.125 OD Tank Assembly 4.0 Gallon...
  • Page 46 Model ZT-1850...
  • Page 47 Model ZT-1850 REF. PART DESCRIPTION 732-0556 Extension Spring .94 OD x 7.57 712-3006 Hex Nut 1/4-20 710-0597 Hex Cap Screw 1/4-20 x 1.0 710-3151 Hex Cap Screw 5/8-18 x 4.25 736-0290 Flat Washer 5/8 ID x 1.0 OD 741-0524 Bearing .625 ID x 1.574 OD 754-3091 Belt 716-3020...
  • Page 48 Model ZT-2150 48 31 45...
  • Page 49 Model ZT-2150 REF. PART DESCRIPTION 720-0241 Wing Nut Knob 703-2817 Belt Cover LH 703-2816 Belt Cover RH 747-3306 Idler Spring Mounting Rod 738-0380 Shoulder Screw 3/8-16 756-3106 Pulley 712-0431 Flange Lock Nut 3/8-16 710-0521 Hex Cap Screw 3/8-16 x 3.0 736-0258 Flat Washer .385 ID x 1.0 OD 756-3105...
  • Page 50 Model ZT-2250 48 31 45...
  • Page 51 Model ZT-2250 REF. PART DESCRIPTION 720-0241 Wing Nut Knob 703-2817 Belt Cover LH 703-2816 Belt Cover RH 747-3306 Idler Spring Mounting Rod 738-0380 Shoulder Screw 3/8-16 756-3106 Pulley 712-0431 Flange Lock Nut 3/8-16 710-0521 Hex Cap Screw 3/8-16 x 3.0 736-0258 Flat Washer .385 ID x 1.0 OD 756-3105...
  • Page 52 Models ZT-2150 & ZT-2250 REF. PART DESCRIPTION 732-0772 Extension Spring 1.25 OD x 11.5 Lg 711-0509 Spring 712-3007 Hex Jam Nut 5/16-18 712-0116 Jam Lock Nut 3/8-24 711-1059 Ferrule 736-0159 Washer 5/16 710-1207 Hex Cap Screw 5/16-18 x 3.50...
  • Page 53 Models ZT-1850, ZT-2150, ZT-2250 629-3070...
  • Page 54 Notes...

  • Page 56: Cleveland, Ohio
