ENG
INSTALLATION FOR DRIPPER SET
1. Screw inlet securely onto a
garden tap.
2. Place the filter in the inlet of
the pressure reducer.
3. Attach the pressure reducer
to the timer.
a. If you want to construct
one dripper system,
use the single output
connector.
b. If you want to construct
two dripper systems,
use the double output
connector.
4. You can start using the timer
once the dripper set is
attached.
5. Turn the large dial to the
required watering time. Time
starts immediately.
6. Turn on the tap.
7. Watering will stop automatically when watering time has
elapsed.
8. Turn off the tap.
4
1
2
3
2a
See the instructions for
Rusta's Dripper set.
2b
