OWNER'S MANUAL
Pro-800W WATT
POWER INVERTER
THE WHISTLER GROUP, INC
CORPORATE HEADQUARTERS
3604 N.W. Frontage Rd.
Bentonville, AR 72712
TEL (479) 273-6012 FAX (479) 273-2927
www.whistlergroup.com
CUSTOMER RETURN CENTER
551 N. 13th St.
Rogers, AR 72756
Customer Service Tel (800) 531-0004
Email: info@whistlergroup.com
P/N 401515
© 2010 The Whistler Group, Inc.
Advertisement
Table of Contents
Related Manuals for Whistler PRO-800W
Summary of Contents for Whistler PRO-800W
- Page 1 CORPORATE HEADQUARTERS 3604 N.W. Frontage Rd. Bentonville, AR 72712 TEL (479) 273-6012 FAX (479) 273-2927 www.whistlergroup.com CUSTOMER RETURN CENTER 551 N. 13th St. Rogers, AR 72756 Customer Service Tel (800) 531-0004 Email: info@whistlergroup.com P/N 401515 © 2010 The Whistler Group, Inc.
- Page 2 If the unit is with our operating instructions. Your new Whistler power inverter allows you to run most AC appliances right from your car, boat or RV. They’re great for weekend use and life on the road. They’re also great for...
-
Page 3: Table Of Contents
“modified sine wave”. See “Technical Operating Principles” section for more information. Depending on the model and its rated capacity, Whistler inverters draw power either from standard 12 volt automobile and marine batteries or from portable high power 12 volt... - Page 4 4/30/2010 9:00 AM Page 7 WHISTLER FEATURES 1. Two 110 AC Outlets 2. On/Off Switch Turns the unit On/Off. 3. On/Shutdown Indicator Light The LED will illuminate GREEN when the inverter is powered in normal conditions. This light will turn RED...
-
Page 5: Important Information
Notes: Your Whistler inverter is designed to operate from a 12 volt power source only. Never attempt to connect your Whistler inverter to any other power source, including any AC power source. -
Page 6: Don't Push It
Page 11 INVERTER BASICS Don’t Push It. Although your Whistler inverter has the capacity to provide power output (excess current) equal to approximately two times its rated wattage capacity for a very brief period, it is designed to operate equipment and appliances with start up load wattage ratings no higher than its own maximum continuous wattage rating. -
Page 7: Operation
Reverse polarity will blow the internal fuses in the inverter and may cause permanent damage to the inverter. Damage caused by reverse polarity is not covered under the Whistler warranty. • Making the connection between the Positive (+) terminals may cause a spark as a result of current flowing to the capacitors in the inverter. - Page 8 pro800w.qxp 4/30/2010 9:00 AM Page 15 OPERATION Run a ground from the Ground Lug Terminal at the rear of the inverter to a proper grounding point using the shortest practical length of 18 AWG wire. Selection of the grounding point will depend on where you are using the inverter.
- Page 9 pro800w.qxp 4/30/2010 9:00 AM Page 17 OPERATION Important Information on Battery Chargers Using your inverter with battery chargers for power tools, flashlights, video cameras and laptop computers may cause damage to the inverter or the charging unit. Check with the appliance manufacturer for compatibility with modified sine wave inverters if you’re unsure.
-
Page 10: Additional & Safety Features
9:00 AM Page 19 ADDITIONAL FEATURES Automatic Shut Down & Related Safety Features. Each Whistler inverter model has an unique LED Indicator warning light system which operates in conjunction with the automatic shut down feature. These indicator lights operate as follows: GREEN LED: System ready. -
Page 11: Care & Maintenance
pro800w.qxp 4/30/2010 9:01 AM Page 21 CARE AND MAINTENANCE Note: Inexpensive sound systems may emit a “buzzing” sound when operated with the inverter. This is due to inadequate filters in the sound system. There is no solution to this problem short of purchasing a sound system with a higher quality power supply. -
Page 12: Operating Principles
Consequently, these meters will not read the RMS modified sine wave voltage correctly and, when measuring your Whistler inverter output, the meters will read about 20 to 30 volts too low. To accurately measure the output voltage of your inverter, use a true RMS reading voltmeter such as a Fluke 87, Fluke 8060A, Beckman 4410, Triplett 4200 or any multimeter identified as "True RMS."... -
Page 13: Operation Summary
Page 25 OPERATION SUMMARY In Review. • Never attempt to operate your Whistler inverter from any power source other than a 12 volt battery or series of batteries that total 12 volts. • This inverter is designed to be connected to the power source with the supplied cables or larger cables that properly match the distance from the battery. -
Page 14: Troubleshooting
pro800w.qxp 4/30/2010 9:01 AM Page 27 TROUBLESHOOTING PROBLEM: TV Interference Problem Solution Electrical interference from Add a Ferrite data line filter inverter. on to the TV power cord. This filter is available at electronic part stores. PROBLEM: Low or No Output Voltage Problem Solution Using incorrect type of... -
Page 15: Specifications
TV is compatible with a modified sine wave. A larger inverter may be required. SPECIFICATIONS Pro-800W WATT INVERTER SPECIFICATIONS Maximum Continuous Power ...800 Watts Maximum Surge Capability (Peak Power)1600 Watts No Load Current Draw...<0.9 A Waveform ...Modified Sine Wave Operating Input Voltage Range11 –... -
Page 16: Warranty
All express or implied warranties for this product are limited to two years. Whistler is not liable for damages arising from the use, misuse, or operation of this product. - Page 17 • The unit has been abused, modified, installed improperly, or had its housing removed. The out of warranty service fee for your 800 watt Whistler inverter is $45.00 (U.S.). If you require out of warranty service, please return your inverter as outlined in the section “Service Under Warranty”...
