CABINET AND DRAWER PARTS

For Model: WVP5000SQ0
Illus. Part
No. No.
1
W10106750 Guide, Use & Care
2 W10011500 Drawer Bin,
3 W10011610 Drawer Front
4 688983 Screw, 8−18 x 5/8
5 3405184 Handle
6 W10113962 Screw,
7 W10011600 Drawer Front
8 W10011320 Top
9 W10116604 Screw, 8−18 x 3/8
10 W10011680 Bracket,
11 W10011660 Clip, Top Lock
12 W10011410 Drawer Bin,
13 W10011420 Slide, Assembly
14 9740848 Screw, 8−18 x 1/2
15 W10070750 Console Assembly
16 W10070490 Bracket, Console
17 3400893 Screw, 8−18 x 5/8
18
19 8563585 Leveling Foot
20 3359452 Nut, Foot
Following Parts Not Illustrated
and Optional Parts Not Included
PAINT, TOUCH−UP (1/2oz.)
72017 White
PAINT, PRESSURIZED SPRAY
(12 oz.)
350930 White
350938 Primer, Gray
(White)
DESCRIPTION
Literature Parts
(Small)
& Handle Assembly
(Top)
8−18 x 1−1/4
& Handle Assembly
(Middle & Bottom)
Top Support
Large (2)
Cabinet
(Not Serviceable)
& Nut
2
8181426
