Summary of Contents for ZyXEL Communications Armor X1
- Page 1 Client Mode Repeater Mode Installation and firmware upgrade instruction Installation and firmware upgrade instruction...
- Page 2 Connect your computer to ARMOR X1 with an Ethernet cable...
- Page 3 Power on your ARMOR X1 by connecting the power adapter to it and plugging it to a wall outlet...
- Page 4 Wait 5 minutes and check that the LED is static red...
- Page 5 1. Open a web browser on the computer and enter: http://zyxelsetup in the address bar 2. Enter password: 1234 3. Click “Login”...
- Page 6 1. Enter a new administrator password to your preference. We recommend you write this down in case you need it in the future. 2. Click “Change”...
- Page 7 Click “Repeater Mode”...
- Page 8 Wait for it to finish scanning...
- Page 9 1. Choose a Wi-Fi network you wish to repeat/extend 2. Click “Continue”...
- Page 10 1. Enter the Wi-Fi network’s password 2. Click “Continue”...
- Page 11 1. Choose a 5 GHz Wi-Fi network you wish to repeat/extend 2. Click “Continue”...
- Page 12 1. Enter the Wi-Fi network’s 1. Enter the Wi-Fi network’s password password 2. Click “Continue” 2. Click “Continue”...
- Page 13 (Optional) Change your repeat/extended Wi-Fi network name and password...
- Page 14 In this example, we added “-ext” to the Wireless Name...
- Page 15 1. Scroll down 2. Click “Apply”...
- Page 16 Wait for it to apply...
- Page 17 If you see this, wait for 5 minutes, then press ‘Reload’ proceed to next step...
- Page 18 1. Open a web browser on the computer and enter: http://zyxelsetup in the address bar 2. Enter your updated administrator password 3. Click “Login”...
- Page 19 Click the Profile icon...
- Page 20 Expand “Maintenance”...
- Page 21 1. Click “Firmware Upgrade” 2. Click “Check For Latest Firmware”...
- Page 22 Click “Upgrade” next to “The Newest Firmware Version”...
- Page 23 Wait a few minutes...
- Page 24 Wait for 2 minutes to restart...
- Page 25 If you land on this page, simply go to the address bar and type in “zyxelsetup/” You may need to try a few times...
- Page 26 If you see this new logo, you have successfully upgraded your ARMOR X1 and completed your setup!
