AUTOMATIC WASHER Use & Care Guide For questions about features, operation/performance, parts, accessories or service call: 1-800-253-1301 In Canada, for assistance call: 1-800-461-5681, for installation and service call: 1-800-807-6777 or visit our website at www.whirlpool.com or www.whirlpool.com/canada Table of Contents...2 3955152A...
TABLE OF CONTENTS WASHER SAFETY ...3 PARTS AND FEATURES ...4 WASHER USE ...5 Understanding Washer Cycles ...5 Loading...5 Normal Sounds ...5 Starting Your Washer...6 Selecting a Cycle and Time ...7 Rinse and Spin ...8 Drain and Spin...8 SMART BLEACH™ Timed Bleach Dispenser ...8 WASHER CARE ...8 Cleaning Your Washer ...8 Water Inlet Hoses ...8...
Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow the safety alert symbol and either the word “DANGER”...
1. Control panel 2. Model and serial number label 3. Liquid fabric softener dispenser 4. CLOTHES SCRUBBER agitator 5. Lid 6. SMART BLEACH ™ timed bleach dispenser Control panel PARTS AND FEATURES 7. DURASMOOTH 8. Tub Additional feature ACCUWASH ™ white porcelain basket ™...
WASHER USE Understanding Washer Cycles When the Cycle Control knob is set to a number and pulled out, the washer fills (to the selected load size) before agitation and timing start. The washer begins agitating immediately after filling; agitation occurs with the washer lid down. During agitation, the agitator creates a continuous rollover action that provides a thorough cleaning of the wash load.
Starting Your Washer Fire Hazard Never place items in the washer that are dampened with gasoline or other flammable fluids. No washer can completely remove oil. Do not dry anything that has ever had any type of oil on it (including cooking oils). Doing so can result in death, explosion, or fire.
6. Set the TEMPERATURE selector to the correct setting for the type of fabric and soils being washed. Use the warmest water safe for fabric. Follow garment label instructions. Your washer uses the ACCUWASH temperature control. The ACCUWASH feature maintains a uniform water temperature by regulating incoming hot and cold water.
Rinse and Spin When using extra detergent for heavily soiled clothes, or washing special-care items, you may find an extra rinse and spin is needed. 1. Push in the Cycle Control knob and turn it clockwise to any of the Rinse settings. 2.
TROUBLESHOOTING First try the solutions suggested here and possibly avoid the cost of a service call... Washer won’t fill, rinse or agitate Check the following: Is the power cord plugged into a grounded 3 prong outlet? Is the indicator on the Cycle Control knob properly lined up with a cycle? Turn the Cycle Control knob to the right slightly and pull to start.
Page 10
The washer basket moves while washing. This is normal. Agitator operation The top of the agitator is loose, or moves in only one direction. This is normal. Dispensers clogged or bleach leaking Did you follow the manufacturer’s directions when adding detergent and fabric softener to the dispensers? Measure detergent and fabric softener.
Canada. For further assistance ® If you need further assistance, you can write to Whirlpool Canada Inc. with any questions or concerns at: Customer Interaction Center Whirlpool Canada Inc.
3. Damage resulting from accident, alteration, misuse, abuse, fire, flood, acts of God, improper installation, installation not in accordance with local electrical and plumbing codes, or use of products not approved by Whirlpool Corporation. 4. Any labor costs during the limited warranty periods.
