Freemotion EPIC GZFI8023.5 Owner's Manual

Lat/high row
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OWNER'S
MANUAL
Model No. GZFI8023.5
Serial No.
Write the serial number in the
space above for future reference.
Serial Number
Decal (inside
of tower)
QUESTIONS?
At FreeMotion Fitness, we are
committed to providing com-
plete customer satisfaction. If
you have questions, see HOW
TO CONTACT CUSTOMER
CARE on the back cover of this
manual.
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
Visit our website at
www.freemotionfitness.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GZFI8023.5 and is the answer not in the manual?

Questions and answers

Related Manuals for Freemotion EPIC GZFI8023.5

Summary of Contents for Freemotion EPIC GZFI8023.5

  • Page 1 OWNER’S MANUAL Model No. GZFI8023.5 Serial No. Write the serial number in the space above for future reference. Serial Number Decal (inside of tower) QUESTIONS? At FreeMotion Fitness, we are committed to providing com- plete customer satisfaction. If you have questions, see HOW...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............3 WARNING DECAL PLACEMENT .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precautions before using the strength equipment. 1. Read all instructions in this manual before 8. The strength equipment is designed to sup- using the strength equipment. Use the port a maximum user weight of 159 kg.

  • Page 4: Warning Decal Placement

    WARNING DECAL PLACEMENT The decals shown below have been placed Decal 3 on the strength equipment in the indicated locations. If a decal is missing or illegible, see HOW TO CONTACT CUSTOMER CARE on the back cover of this manual to order a free replacement decal.

  • Page 5: Before You Begin

    The model The innovative features and quality construction provide number is GZFI8023.5. The serial number can be found a reliable product for your club. And the advanced solu- on a decal attached to the strength equipment (see the tions to isolating individual muscle groups make the front cover of this manual).

  • Page 6: Adjustments

    ADJUSTMENTS This section explains how to adjust the strength equipment. Make sure all parts are properly tightened each time the strength equipment is used. Replace any worn parts immediately. ADJUSTING THE RESISTANCE To change the amount of resistance for your workout, Weight insert the weight pin into the desired weight.

  • Page 7: Maintenance

    To maintain the strength equipment’s warranty, use only FREEMOTION EPIC parts for repair or replacement. If there are any questions or concerns, see HOW TO CONTACT CUSTOMER CARE on the back cover of this manual.
  • Page 8 CABLE TENSION CHECK MONTHLY 1. Grips: 1. Insert the weight pin into the top weight plate. • Check and replace as needed. 2. Slowly raise and lower the top weight by normal YEARLY OR AS REQUIRED machine use. The top weight should come to rest just on top of the second weight when the 1.
  • Page 9 CABLE ADJUSTMENTS CAUTION: After making any cable adjustment, pull Tower Pulley Adjustment– the handle using a light load and have someone Tools required: 5/16" hex key, 9/16" open end make sure that the cable is not derailed from a pulley wrench/spanner or rubbing on a guard (see CABLE GUARDS on page 10).
  • Page 10 Top Weight Adjustment— CABLE GUARDS Tools required: 5/32” hex key Check for alignment periodically to ensure that cable 1. If the cable needs to be shortened 2 cm (3/4 in.) guards are not rubbing on the cable and that they are or more, follow the instructions in step 1 in the performing their intended duty.
  • Page 11 SERVICING THE WEIGHT STACK Servicing the weight stack involves replacing the two 9. Reattach the cable to the top weight coupler. guide bushings and weight insert in the top weight. To Retighten the four set screws into the threaded order these parts, see HOW TO CONTACT CUS- holes.

  • Page 12: Cable Diagram

    CABLE DIAGRAM The cable diagram below shows the proper route of the cables. Use the diagram to make sure that the cables and the cable guards have been assembled correctly. If the cables have not been correctly routed, the strength equipment will not function properly and damage may occur.
  • Page 13 NOTES...

  • Page 14: Part List

    PART LIST—Model No. GZFI8023.5 R0206A If replacement parts are needed, or if parts are missing or damaged, see HOW TO CONTACT CUSTOMER CARE on the back cover of this manual. Key No. Qty. Description Key No. Qty. Description Frame Thigh Pad...

  • Page 15: Exploded Drawing

    EXPLODED DRAWING—Model No. GZFI8023.5 R0206A 32 52 28 64...

  • Page 16: How To Contact Customer Care

    Please be prepared to provide the following information: • The MODEL NUMBER of the product (GZFI8023.5). • The NAME of the product (FREEMOTION EPIC LAT/HIGH ROW strength equipment). • The SERIAL NUMBER of the product (see the front cover of this manual).
