RANGE HOOD PARTS
For Model: RH2330XJQ1, RH2330XJZ1, RH2330XJB1, RH2330XJT1
(Designer White) (Almond)
(Black)
(Biscuit)
Illus.
No.
1
2
5
6
7
8
9
10
11
12
13
16
18
19
LITERATURE PARTS
1
30" RANGE HOOD
(Vented)
(Use with Gas or Electric Range)
Part
No.
DESCRIPTION
883191 Installation
Hardware
Switch, Light
8189843 White Model
8189845 Black Model
8189844 Almond Model
8189846 Biscuit Model
883103 Filter, With Lens
Nameplate
8189511 White Model
8189512 Almond Model
8189513 Black Model
8189514 Biscuit Model
Switch, Fan
8189847 White Model
8189849 Black Model
8189848 Almond Model
8189850 Biscuit Model
883094 Light Socket
883382 Blade, Fan
883378 Motor/Fan Assembly
883397 Bracket, Motor
830465 Screw, 8 x 1/4
Cover, wiring
883095 White
883096 Almond/Biscuit
883169 Black
883353 Nut, 6−32 (2)
883354 Screw,
8−32 x 1/4 (2)
830753 Damper
LIT830735 Order Blank,
Filter
LIT8284867 Installation
& Operating
Instructions
LIT883184 Wiring Diagram
Part No. 8189836
Advertisement
Table of Contents
Need help?
Do you have a question about the RH2330XJB1 and is the answer not in the manual?
Questions and answers
How do you remove the filter and light cover from range hood rh2330xjb1. There are no tabs to use to pull down.
