PRODUCT MODEL NUMBERS
GZ9730XS
GZ9736XS
A 120 Volt, 60Hz., AC only 15-amp fused, electrical supply (or circuit
breaker) is required. (A time-delay fuse or circuit breaker is
recommended.) It is recommended that a separate circuit serving only
this appliance be provided.
Set the grounded 3 prong outlet within the space covered by the
decorative flues.
VENTING REQUIREMENTS
Roof Venting
Wall Venting
A
B
A. Roof cap
A. Wall cap
B. 6" (15.2 cm)
B. 6" (15.2 cm)
round vent
Calculating Vent System Length
To calculate the length of the system you need, add the
equivalent feet (meters) for each vent piece used in the system.
Vent Piece
45° elbow
90° elbow
3-1/4" x 10" (8.3 cm x 25 cm) vent system
3-1/4" x 10"
(8.3 cm x 25 cm)
elbow
2 ft.
(0.6 m)
Note:
Flexible vent is
Not recommended.
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
30" (76.2cm) and 36" (91.4cm) Wall-Mount Range Hood
Non-vented
(recirculating)
B
B
A
A. Deflector
B. 6" (15.2 cm)
round vent
round vent
6" (15.2 cm) Round
2.5 ft
(0.8 m)
5.0 ft
(1.5 m)
6 ft. (1.8 m)
Maximum length
= 35 ft. (10.7 m)
1 — 90° elbow
= 5.0 ft. (1.5 m)
8 ft. (2.4 m) straight
= 8.0 ft. (2.4 m)
1 — wall cap
= 0.0 ft. (0 m)
Length of system
=13.0 ft. (3.9 m)
OVERALL DIMENSIONS
A
CABINET OPENING DIMENSIONS
wall
cap
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
8
"
10
"
(25.2 cm)
(27.8 cm)
"
(20 cm)
30" (76.2 cm)
or
36" (91.4 cm)
30" (76.2 cm)
or
36" (91.4 cm)
24" (61 cm) min.
30" (76.2 cm) suggested max.
32"
(81.3 cm) min.
46 "
(117.2 cm) max.
19
"
(48.4 cm)
5
"
(12.9 cm)
19 "
(49.8 cm)
33
"
(85 cm)
max.
12" (30.5 cm) min.
14" (35.6 cm) max.
Ref. W100297700A
1-22-08
