Determine location of lock. Open drawer. Align tem-
1
plate (inside of drawer) with top edge of drawer.
Note: Illustrations below shows inside view of cabinet.
4
Using power tools, drill a 22 mm (0.87") center hole
2
through drawer. Drill two 2.5 mm (0.1") holes for anti-
rotation prongs on lock. Caution: Do not drill prong
holes through drawer, only 4 mm depth needed.
Anti-Rotation
Prongs
Center Hole
22 mm (0.87")
Anti-Rotation
Prong Holes
2.5 mm (0.1")
