- Page 3 Cabinet (Not A Serviceable Part) 944766 Leveler 937216 Roller, Front & Rear (4) 489179 Screw 489297 Screw (Repair) 940024 Spacer 534365 Breaker, Trim Clip (3) 1108139 Heater, Mullion 1110231 Center Rail, Bracket (2) 489169 Screw (2) 488844 Screw, 8-32 x 1/2 (2) Hole Plug (2) 1122929 White...
- Page 4 1119401 Almond 1119403 Platinum 1119402 Toast Cover, Glider Rail 943552 White 944831 Almond 944833 Golden Harvest 1100681 Platinum 1100682 Toast Filler, Wrap Corner (2) 1118058 White 1118060 Golden Harvest 1118059 Almond 1118062 Platinum 1118061 Toast Hole Plug 1119707 White 1119709 Almond 1119708 Golden Harvest...
- Page 6 Liner (Not A Serviceable Part) 1127626 Wiring, Fan Motor 941839 Hole Plug (2) 942751 Side, Electric Shield 1129068 Top, Electric Shield 942750 Stud, Evaporator (2) 939065 Stud Hook 1123230 Clip, Strap 1118775 Cover, Air Duct 489242 Screw 489254 Screw (Repair) 1105608 Motor, Fan 1100938...
- Page 8 1111796 Bottom, Compartment Separator 1126703 Box, Control 1108112 Switch, Rocker Arm 1114283 Timer, Defrost (8 Hour) 488693 Screw, 6-20 x 1/2 1105166 Switch, Toggle 851067 Socket Assembly 946059 Bulb, Light 940014 Hole Plug 1114241 Thermostat Barrier Assembly 1111759 Knob, Thermostat 1108358 Drain Pan 1126711...
- Page 10 943719 Shelf, Pullout (3) 1103731 Support Cover, Crisper 1110144 Cover, Crisper 836410 Post, Crisper Cover 1100799 Shelf, Ice Cube Pan 943718 Trim, Shelf (3) 1110145 Cover, Meat Pan 1111863 Crisper Pan 1116012 Pan, Meat 1100125 Trim, Shelf 841180 Tray, Ice (2)
- Page 12 Panel, Freezer Door (Also Order Item 21) 1104640 White 1104642 Golden Harvest 1104644 Almond 1104645 Toast 1104646 Platinum Hole Plug (2) 534927 White 989197 Almond 989879 Golden Harvest 1100196 Toast 1100197 Platinum 943185 Plate, Tap (4) 944035 Bracket, Door Stop 489220 Screw 489224...
- Page 14 1103640 Bumper (2) 1108183 Condenser & Precooler Assembly 1118652 Clip, Tube (2) 1108073 Sleeve 1105130 Spacer 1108359 Heat Shield Evaporator 510716 Tube Clamp 945593 Dampener 488480 Screw, 8 x 1/2 (2) 938384 Spring, Relay Case 1108115 Case, Relay 1105163 Overload 946615 Relay 934326...
- Page 15 978030 Valve, Access (3/4") 876764 Valve, Access (3/16")
- Page 17 Panel, Refrigerator Door (Also Order Item 27) 1104632 White 1104634 Golden Harvest 1104636 Almond 1104637 Toast 1104638 Platinum 534927 Hole Plug (2) 943185 Plate, Tap (4) 1115910 Bracket, Door Stop 489220 Screw 489224 Screw 489221 Screw (Repair) Hole Plug 844478 White 989196 Almond...
- Page 18 799833 Kit, Evaporator Repair (Aluminum Epoxy) 503695 Cork Sealer (1/4 Pound) Customer Touch Up Material 350942 *Primer, White (13 Oz. Spray Can) 350941 *Leveler, Enamel (13 Oz. Spray Can) 350939 *Enamel, Black (13 Oz. Spray Can) 350930 *Enamel, White (13 Oz. Spray Can) 261890 *Enamel, Golden Harvest (13 Oz.
