Cooktop Use - Whirlpool W10200354B User Instructions

Electric range
Hide thumbs

Advertisement

WARNING
Fire Hazard
Turn off all controls when done cooking.
Failure to do so can result in death or fire.
The control knobs can be set to anywhere between HI and LO.
Push in and turn to setting.
REMEMBER: When range is in use or (on some models)
during the Self-Cleaning cycle, the entire cooktop area may
become hot.
Ceramic Glass
The surface cooking area will glow red when an element is on. It
may cycle on and off to maintain the selected heat level.
Use cookware about the same size as the surface cooking area.
Cookware should not extend more than ½" (1.3 cm) outside the
area.
Cleaning off the cooktop before and after each use will help keep it
free from stains and provide the most even heating.
Hot Surface Indicator Light
The Hot Surface indicator light is located on the console panel.
The Hot Surface indicator light will glow as long as any surface
cooking area is too hot to touch, even after the surface cooking
area is turned off.
Cooktop On Indicator Light
The Cooktop On indicator light is located on the console panel.
When any control knob on the console panel is turned on, the
Cooktop Indicator light will glow.
6

COOKTOP USE

Dual Cooking Zone
The Dual Cooking Zone offers flexibility depending on the size of
the cookware. Single size can be used in the same way as a regular
element. The dual size combines both the single and outer element
and is recommended for larger size cookware.
Triple Cooking Zone
The Triple Cooking Zone offers flexibility depending on the size of
the cookware. Single size can be used in the same way as a regular
element. The dual and triple sizes combine single, dual and outer
element and are recommended for larger size cookware, large
quantities of food, and home canning.
Warm Zone Element (on some models)
Do not let food sit in oven more than one hour before
or after cooking.
Doing so can result in food poisoning or sickness.
Use the Warm Zone element to keep cooked foods warm. One
hour is the recommended maximum time to maintain food quality.
Do not use it to heat cold foods.
The Warm Zone element can be used alone or when any of the
other surface cooking areas are being used.
The Warm Zone element area will not glow red when cycling on.
However, its indicator light will glow as long as the Warm Zone
element area is too hot to touch.
A
B
A. Dual
B. Single
A
C
A. Single
B. Triple
C. Dual
WARNING
Food Poisoning Hazard
B
