Whirlpool TGP302 Use And Care Manual

Estate by whirlpool gas range use & care guide
Hide thumbs

Advertisement

Quick Links

GAS RANGE
Use & Care Guide
Table of Contents...................................................2
MODELS TGP325 TGP310 TGP302
TO THE INSTALLER: PLEASE LEAVE THIS
INSTRUCTION BOOK WITH THE UNIT.
TO THE CONSUMER: PLEASE READ AND KEEP
THIS BOOK FOR FUTURE REFERENCE.
8522717

Advertisement

loading

  Related Manuals for Whirlpool TGP302

  Summary of Contents for Whirlpool TGP302

  • Page 1 GAS RANGE Use & Care Guide Table of Contents...2 MODELS TGP325 TGP310 TGP302 TO THE INSTALLER: PLEASE LEAVE THIS INSTRUCTION BOOK WITH THE UNIT. TO THE CONSUMER: PLEASE READ AND KEEP THIS BOOK FOR FUTURE REFERENCE. 8522717...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS RANGE SAFETY ... 3 The Anti-Tip Bracket ...4 PARTS AND FEATURES ... 5 COOKTOP USE ...6 Cooktop Controls...6 Surface Burners ...6 Lift-up Cooktop ...7 Home Canning ...8 Cookware ...8 ELECTRONIC OVEN CONTROL... 9 Oven Indicator Lights ...9 Display ...9 Start/Enter ...9 Off/Cancel ...9...
  • Page 3: Range Safety

    Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow the safety alert symbol and either the word “DANGER”...
  • Page 4: The Anti-Tip Bracket

    The range will not tip during normal use. However, the range can tip if you apply too much force or weight to the open door without the anti-tip bracket fastened down properly. A child or adult can tip the range and be killed. Connect anti-tip bracket to rear range foot.
  • Page 5: Parts And Features

    This manual covers several different models. The range you have purchased may have some or all of the parts and features listed. The locations and appearances of the features shown here may not match your model. Control Panels 1. Display (on some models) 1.
  • Page 6: Cooktop Use

    COOKTOP USE Cooktop Controls WARNING Fire Hazard Do not let the burner flame extend beyond the edge of the pan. Turn off all controls when not cooking. Failure to follow these instructions can result in death or fire. Electric ignitors automatically light the surface burners when control knobs are turned to LIGHT.
  • Page 7: Lift-Up Cooktop

    To Clean: 1. Remove the burner cap from the burner base and clean according to “General Cleaning” section. 2. Clean the gas tube opening with a damp cloth. 3. Clean clogged burner ports with a straight pin as shown. Do not enlarge or distort the port.
  • Page 8: Home Canning

    Home Canning When canning for long periods, alternate the use of surface cooking areas, elements or surface burners between batches. This allows time for the most recently used areas to cool. Center the canner on the grate or largest surface cooking area or element.
  • Page 9: Electronic Oven Control

    ELECTRONIC OVEN CONTROL 1. Indicator Lights 2. Electronic Display 3. Off/Cancel pad Oven Indicator Lights The indicator lights are located to the left of, below, and within the display. The indicator lights light up or flash when the oven is in one of the following modes: BAKE, BROIL, HEAT, START?, ON, TIMER, COOK TIME/TIMED cooking (on some models), and START TIME/DELAY cooking (on some models).
  • Page 10: Oven Temperature Control

    Oven Temperature Control IMPORTANT: Do not use a thermometer to measure oven temperature because opening the oven door and element or burner cycling may give incorrect readings. The oven provides accurate temperatures; however, it may cook faster or slower than your previous oven, so the temperature calibration can be adjusted.
  • Page 11: Bakeware

    Bakeware The bakeware material affects cooking results. Follow manufacturer’s recommendations and use the bakeware size recommended in the recipe. Use the following chart as a guide. BAKEWARE/ RECOMMENDATIONS RESULTS Light colored Use temperature and time aluminum recommended in recipe. Light golden crusts Even browning Dark aluminum...
  • Page 12: Broiling And Custom Broiling

    Preheating After START/ENTER is pressed, the oven will enter a timed preheat conditioning. “PrE” and the time countdown will appear on the display. When the preheat conditioning time ends, a tone will sound and the selected temperature will appear on the display.
  • Page 13: Timed Cooking

    Timed Cooking (on some models) WARNING Food Poisoning Hazard Do not let food sit in oven more than one hour before or after cooking. Doing so can result in food poisoning or sickness. Timed Cooking allows the oven to be set to turn on at a certain time of day, cook for a set length of time, and/or shut off automatically.
  • Page 14: Timer

    Timer The Timer can be set in minutes and seconds or hours and minutes and counts down the set time. The Timer does not start or stop the oven. To Set: 1. Press TIMER. The colon will flash during Timer programming. 2.
  • Page 15: Oven Use

    OVEN USE Baking and Roasting Before baking and roasting, position the racks according to the “Positioning Racks and Bakeware” section. When roasting, it is not necessary to wait for the oven to preheat before putting food in, unless recommended in the recipe. To Bake or Roast: 1.
  • Page 16: Range Care

    To Broil: 1. Open the broiler door and roll out the broiler pan and grid. 2. Place the broiler pan and grid so grease can drain down into the lower part of the broiler pan. 3. Place food on broiler pan. Then place the pan on the broiler rack and close the broiler door.
  • Page 17: General Cleaning

    General Cleaning IMPORTANT: Before cleaning, make sure all controls are off and the oven and cooktop are cool. Always follow label instructions on cleaning products. Do not wipe down any of the inside surfaces until the oven has completely cooled down. Applying a cool damp cloth to the inner door glass before it has cooled completely could result in the glass breaking.
  • Page 18: Oven Door

    Oven Door For normal range use, it is not suggested to remove the oven door. However, if necessary, follow these instructions. The oven door is heavy. Before Removing: 1. Use a putty knife or screwdriver and insert it at the bottom corner of the door stop clip.
  • Page 19: Assistance Or Service

    To locate the Whirlpool designated service company in your area, you can also look in your telephone directory Yellow Pages. For further assistance If you need further assistance, you can write to Whirlpool Corporation with any questions or concerns at: Estate Brand Home Appliances Customer Interaction Center...
  • Page 20: Warranty

    CLEANTOP Whirlpool Corporation warrants that the ceramic glass cooktop will not discolor, the cooktop pattern will not wear off, the rubber seal between the ceramic glass cooktop and porcelain edge will not crack, the ceramic glass cooktop will not crack due to thermal shock and the surface unit elements will not burn out.

This manual is also suitable for:

Tgp310Tgp325
