TO THE INSTALLER: PLEASE LEAVE THIS INSTRUCTION
BOOK WITH THE UNIT.
TO THE CONSUMER: PLEASE READ AND KEEP THIS
BOOK FOR FUTURE REFERENCE.
4.65 Cubic Foot Oven
MODELS SF365PEG SF367LEH
8053423B
Self-Cleaning
Gas Range
A Note to You ............2
Range Safety .............3
Parts and Features ....5
Using Your Range......6
Cleaning Cycle.........18
Range.......................21
Troubleshooting.......27
Index ........................31
Warranty...................32
1 - 800 - 253 - 1301
Call our Consumer Assistance Center
with questions or comments.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Whirlpool SF365PEG
Summary of Contents for Whirlpool SF365PEG
-
Page 1: Table Of Contents
TO THE INSTALLER: PLEASE LEAVE THIS INSTRUCTION BOOK WITH THE UNIT. TO THE CONSUMER: PLEASE READ AND KEEP THIS BOOK FOR FUTURE REFERENCE. 4.65 Cubic Foot Oven MODELS SF365PEG SF367LEH 8053423B Self-Cleaning Gas Range A Note to You ...2 Range Safety ...3 Parts and Features ...5... -
Page 2: A Note To You
Thank you for buying a WHIRLPOOL The Whirlpool Brand is committed to designing quality products that consistently perform for you to make your life easier. To ensure that you enjoy years of trouble-free operation, we developed this Use and Care Guide. -
Page 3: Range Safety
ANGE AFETY Your safety and the safety of others is very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to hazards that can kill or hurt you and others. All safety messages will be preceded by the safety alert symbol and the word “DANGER”... -
Page 4: Important Safety Instructions
RANGE SAFETY IMPORTANT SAFETY INSTRUCTIONS WARNING: To reduce the risk of fire, electrical shock, injury to persons, or damage when using the range, follow basic precautions, including the following: • WARNING – TO REDUCE THE RISK OF TIPPING OF THE RANGE, THE RANGE MUST BE SECURED BY PROPERLY INSTALLED ANTI-TIP DEVICES. -
Page 5: Parts And Features
ARTS AND EATURES (SF365PEG shown) (SF367LEH not shown) Oven vent (p. 17) Surface burners and grates (pp. 21, 23-24) Anti-tip bracket (p. 3) Door stop clip (pp. 24-26) Model and serial number plate (behind left side of storage drawer) Storage drawer (p. -
Page 6: Using The Surface Burners
SING ANGE SING THE SURFACE BURNERS wWARNING Fire Hazard Do not let the burner flame extend beyond the edge of the pan. Turn off all controls when not cooking. Failure to follow these instructions can result in death or fire. Using the control knobs Your range comes with electric ignitors. -
Page 7: Characteristics Of Cookware Materials
SING THE SURFACE BURNERS In case of a prolonged power failure You can manually light surface burners. Hold a lit match near a burner and turn the control knob to the LIGHT position. After the burner lights, turn the control knob to the setting you want. Home canning information The large diameter of most water-bath or pressure canners combined with high heat settings for long... -
Page 8: Using The Oven
USING YOUR RANGE SING THE OVEN Positioning racks and pans Place the oven racks where you need them before turning on the oven. • To move a rack, pull it out to the stop position, raise the front edge and lift it out. •... -
Page 9: Using Aluminum Foil
SING ALUMINUM FOIL • Do not line the oven bottom with any type of foil, liners, or cookware. Permanent damage will occur to the oven bottom finish. • Do not block the oven bottom vents. • Do not cover the entire rack with aluminum foil. Doing so will reduce air circulation and overall oven performance. -
Page 10: Setting The Clock
USING YOUR RANGE HE ELECTRONIC TIME - OF - DAY ( TOD ) CLOCK Clock pad (pp. 10, 14) Oven timer pad (p. 11, 12) Display/clock • When you first plug in the range, “PF” will appear on the display. If “PF” appears again on the display, your electricity was off for a while. -
Page 11: Using The Electronic Timer
SING THE ELECTRONIC TIMER The timer does not start or stop the oven. It works like a kitchen timer. It can be set in hours and min- utes up to 12 hours, 59 minutes. The timer will dis- play minutes for settings under 1 hour and hours and minutes for settings over 1 hour. - Page 12 USING YOUR RANGE SING THE ELECTRONIC TIMER When there is 1 minute of time remaining, the display will begin counting down in seconds. When the timer countdown reaches zero, the display will show “End” and you will hear four 1-second tones. To cancel the timer: Press TIMER twice while in the timer mode.
- Page 13 AKING ROASTING ( CONT Put your food in the oven. During baking/roasting, the burner will turn on and off to keep the oven temperature at the setting. After baking/roasting, push and turn the oven control knob to OFF. Saving energy •...
-
Page 14: Adjusting The Oven Temperature Control
USING YOUR RANGE DJUSTING THE OVEN TEMPERATURE CONTROL Although your new oven is properly adjusted to provide accurate temperatures, it may cook faster or slower than your old oven. If you are not satisfied with the baking/roasting results, you can change the offset temperature by following the steps below. - Page 15 ROILING NOTES: • Do not preheat when broiling unless your recipe recommends it. Place the rack where you need it in the oven. See “Broiling guide lines” later in this section. Front Rear Put your food on the broiler pan and place the pan in the center of the oven rack.
- Page 16 USING YOUR RANGE ROILING ( CONT Broiling guidelines • Use only the broiler pan and grid provided. They are designed to drain extra juices from the cooking surface. This drainage helps prevent spatter and smoke. • To make sure the juices drain well, do not cover the grid with foil.
-
Page 17: The Oven Vent
HE OVEN VENT Hot air and moisture escape from the oven through a vent that is near the middle of the backguard. The vent lets air circulate properly. Be careful not to block the vent, or you will get poor baking/roasting results. -
Page 18: Self-Cleaning Cycle
SING THE Do not touch the oven during the Self-Cleaning cycle. Keep children away from oven during Self-Cleaning cycle. Do not use commercial oven cleaners in your oven. Failure to follow these instructions can result in burns, or illness from inhaling dangerous fumes. -
Page 19: Setting The Controls
ETTING THE CONTROLS Set the oven control knob to CLEAN. The door will lock itself within 6 seconds. If the door has a problem locking, it will try to lock itself for 1 minute. If the door fails to lock, the Self-Cleaning cycle will cancel. -
Page 20: How The Cycle Works
USING THE SELF-CLEANING CYCLE ETTING THE CONTROLS To stop the self-cleaning cycle at any time: Turn the oven control knob to OFF. OW THE CYCLE WORKS The Self-Cleaning cycle uses very high heat to burn away soil and grease. During the cycle, the oven gets much hotter than it does for normal bak- ing or broiling. -
Page 21: Cleaning Chart
ARING FOR LEANING CHART Before cleaning, always make sure all controls are off and the range is cool. Refer to instructions on all cleaning products before using them to clean your range. PART Control Knobs Control Panel Exterior Surfaces* (excluding control panel and oven door glass) Surface burner grates and caps* •... -
Page 22: Caring For Your Range
CARING FOR YOUR RANGE LEANING CHART ( CONT PART Surface burners Oven door glass Oven cavity • Food spills containing sugar and/or milk • All other spills Oven racks Broiler pan and grid CLEANING METHOD • Soap and water • Non-abrasive plastic scrubbing pad •... -
Page 23: Sealed Surface Burners And Cooktop
EALED SURFACE BURNERS AND COOKTOP Cleaning the surface burners • You should routinely remove and clean the burner cap. Always clean the burner cap after a spill- over. Keeping the burner cap clean prevents improper ignition and an uneven flame. •... -
Page 24: Removing The Oven Door
CARING FOR YOUR RANGE EALED SURFACE BURNERS AND COOKTOP To clean the burners: Pull the burner cap straight up from the burner base. Clean the burner cap with warm, soapy water and a sponge. You can also clean it with a mildly abrasive scrubbing pad or cleanser. - Page 25 EMOVING THE OVEN DOOR To remove: Open the oven door. Insert door removal pins, included with your range, into both hinge hangers. Do not remove the pins while the door is re- moved from the range. Carefully close the door until it rests against the door removal pins.
-
Page 26: The Oven Light
CARING FOR YOUR RANGE EMOVING THE OVEN DOOR Hold oven door so that the top edge of each hinge hanger is horizontal. Insert hinge hangers into the front frame hinge slots. Tilt top of door toward range. Slide hinge hangers down onto front frame support pins. NOTE: Make sure the hinge hangers are fully seated and engaged on the support pins. -
Page 27: Troubleshooting
ROUBLESHOOTING Most cooking problems often are caused by little things you can find and fix without tools of any kind. Check the lists below and on the next page before calling for assistance or service. If you still need help, see “Requesting Assistance or Service” on page 29. ANGE DOES NOT WORK PROBLEM CAUSE... -
Page 28: Requesting
TROUBLESHOOTING HEN SELF CLEANING YOUR OVEN PROBLEM The Self-Cleaning cycle will not work OOKING RESULTS PROBLEM Cookware not level on cooktop (Check to see if liquids are level in cookware) Excessive heat on cooktop in areas around cookware The oven temperature seems too low or too high Slow baking or roasting Baked items too brown... -
Page 29: Assistance Or Service
When calling: Please know the purchase date, and the complete model and serial number of your appliance (see the “A Note to You” section). This information will help Whirlpool better respond to your request. Our consultants provide assistance with: •... -
Page 30: Index
NDEX TOPIC ANTI-TIP BRACKET...3 ASSISTANCE ...29 BAKING Aluminum foil ...9 Bakeware ...9 Pans ...7, 8 Racks ...8 Setting cycle ...12, 13 Tips...13 BROILING Grid...16 Guidelines...16 Pan ...15, 16 Setting cycle...15 CLEANING Broiler pan and grid ...22 Control knobs...21 Control panel ...21 Exterior surfaces ...21 Oven cavity ...22 Oven door glass ...22... -
Page 31: Warranty
If you need service, first see the “Troubleshooting” section of this book. After checking “Troubleshooting,” additional help can be found by checking the “Requesting Assistance or Service” section, or by calling the Whirlpool Consumer Assistance Center telephone number, 1-800-253-1301, from anywhere in the U.S.A. 8053423B ©...
