Summary of Contents for Whirlpool SES380MS0
- Page 1 ELECTRIC RANGE Use & Care Guide For questions about features, operation/performance parts, accessories or service, call: 1-866-403-5448. Table of Contents ... 2 9756097...
-
Page 2: Table Of Contents
TABLE OF CONTENTS RANGE SAFETY ...3 The Anti-Tip Bracket ...3 PARTS AND FEATURES...6 COOKTOP USE ...7 Cooktop Controls...7 Ceramic Glass ...7 Home Canning ...8 Cookware ...8 ELECTRONIC OVEN CONTROL ...9 Oven Indicator Lights ...9 Display...9 Start/Enter ...9 Off/Cancel ...9 Clock ...9 Timer...9 Control Lock...9 Oven Temperature Control ...10... -
Page 3: Range Safety
Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow the safety alert symbol and either the word “DANGER”... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING: To reduce the risk of fire, electrical shock, injury to persons, or damage when using the range, follow basic precautions, including the following: WARNING: TO REDUCE THE RISK OF TIPPING OF THE RANGE, THE RANGE MUST BE SECURED BY PROPERLY INSTALLED ANTI-TIP DEVICES. - Page 5 IMPORTANT SAFETY INSTRUCTIONS Keep Oven Vent Ducts Unobstructed. Placement of Oven Racks – Always place oven racks in desired location while oven is cool. If rack must be moved while oven is hot, do not let potholder contact hot heating element in oven. DO NOT TOUCH HEATING ELEMENTS OR INTERIOR SURFACES OF OVEN –...
-
Page 6: Parts And Features
Control Panel 1. Left Front Control Knob 2. Surface Heating Indicator Light Range 1. Surface Cooking Area or Element 2. Anti-Tip Bracket 3. Door Stop Clip 4. Model and Serial Number Plate (behind left side of storage drawer) 5. Storage Drawer 6. -
Page 7: Cooktop Use
COOKTOP USE Cooktop Controls WARNING Fire Hazard Turn off all controls when done cooking. Failure to do so can result in death or fire. The control knobs can be set anywhere between HI and LO. Push in and turn to setting. The surface cooking area locator shows which element is turned on. -
Page 8: Home Canning
Hot Surface Indicator Light (under ceramic glass) The hot surface indicator light will glow as long as any surface cooking area is too hot to touch, even after the surface cooking area(s) is turned off. HOT SURFACE HOT SURFACE Home Canning When canning for long periods, alternate the use of surface cooking areas, elements or surface burners between batches. -
Page 9: Electronic Oven Control
ELECTRONIC OVEN CONTROL 1. Display 6. Off/Cancel 2. Clock 7. Temperature/Time 3. Timer Cancel* 8. Cook Time 4. Start/Enter (Control Lock) 9. Start Time 5. Auto Clean 10. Custom Broil 11. Bake Oven Indicator Lights The indicator lights are located to the left of, and within the display. -
Page 10: Oven Temperature Control
Oven Temperature Control IMPORTANT: Do not use a thermometer to measure oven temperature because opening the oven door and element or burner cycling may give incorrect readings. The oven provides accurate temperatures; however, it may cook faster or slower than your previous oven, so the temperature calibration can be adjusted. -
Page 11: Oven Vent
BAKEWARE/ RECOMMENDATIONS RESULTS Insulated cookie Place in the bottom third of oven. sheets or baking May need to increase baking time. pans Little or no bottom browning Stainless steel May need to increase baking time. Light, golden crusts Uneven browning Stoneware Follow manufacturer’s instructions. -
Page 12: Timed Cooking
To Broil: 1. Press CUSTOM BROIL. The “BROIL” indicator and “TEMP” arrow will light up. “500” will show on the oven display. 2. Press START/ENTER. The On indicator lights will light up. The temperature setting can be changed any time before or after pressing START/ENTER. -
Page 13: Range Care
RANGE CARE Self-Cleaning Cycle (on some models) WARNING Burn Hazard Do not touch the oven during the Self-Cleaning cycle. Keep children away from oven during Self-Cleaning cycle. Failure to follow these instructions can result in burns. IMPORTANT: The health of some birds is extremely sensitive to the fumes given off during the Self-Cleaning cycle. - Page 14 STAINLESS STEEL (on some models) Do not use soap-filled scouring pads, abrasive cleaners, Cooktop Polishing Creme, steel-wool pads, gritty washcloths or some paper towels. Damage may occur. Rub in direction of grain to avoid damaging. Stainless Steel Cleaner & Polish (not included): See “Assistance or Service”...
-
Page 15: Oven Light
Oven Light The oven light is a standard 40-watt appliance bulb. It will come on when the oven door is open. It will not work during the Self- Cleaning cycle. On some models, when the oven door is closed, press OVEN LIGHT to turn it on or off. Before replacing, make sure the oven and cooktop are cool and the control knobs are in the off position. -
Page 16: Troubleshooting
TROUBLESHOOTING Try the solutions suggested here first in order to avoid the cost of an unnecessary service call. Nothing will operate Is the power supply cord unplugged? Plug into a grounded outlet. Has a household fuse been blown or has the circuit breaker been tripped? Replace the fuse or reset the circuit. -
Page 17: Assistance Or Service
To locate the Whirlpool designated service company in your area, you can also look in your telephone directory Yellow Pages. For further assistance If you need further assistance, you can write to Whirlpool Corporation with any questions or concerns at: Whirlpool Corporation Customer Interaction Center ®... - Page 18 Notes...
- Page 19 Notes...
-
Page 20: Warranty
Whirlpool Corporation warrants that the ceramic glass cooktop will not discolor, the cooktop pattern will not wear off, the rubber seal between the ceramic glass cooktop and porcelain edge will not crack, the ceramic glass cooktop will not crack due to thermal shock and the surface unit elements will not burn out.
