Model/Modelo/Modèle
PTT298510
Series/Series/Seria
Write purchased model number here.
Escriba aquí el número del modelo comprado.
Inscrivez le numéro de modèle ici.
You may need/Usted puede necesitar/Articles dont vous pouvez avoir besoin:
1/8" (3.17mm)
For easy installation of your Delta faucet
you will need:
・To READ ALL the instructions completely before
beginning.
・To READ ALL warnings, care and maintenance
information.
・To complete the deck and valve rough-in prior to
installing this trim kit.
Para instalación fácil de su llave Delta
usted necesitará:
・LEER TODAS las instrucciones completamente
antes de empezar.
・LEER TODAS los avisos, cuidados, e información
de mantenimiento.
・Para completar el borde y la instalación de válvulas
dentro de las paredes previa a la instalación de la llave
y sus accesorios.
Pour installer votre robinet Delta
facilement, vous devez:
・LIRE TOUTES les instructions avant de débuter.
・LIRE TOUE les avertissements ainsi que toutes
les instructions de nettoyage et d'entretien.
・Installez le corps du robinet et terminez le pourtour du
bain avant de poser les accessories de finition.
www.peerlessfaucet.com
TWO HANDLE ROMAN TUB TRIM
86640
LLAVEY SUS ACCESORIOS
PARA BAÑERA ROMANA DE DOS MANIJAS
(MANERALES)
ACCESSOIRES DE FINITION DE ROBINET À
DEUX POIGNÉES POUR BAIN ROMAIN
86640
1
1/8" (3.17mm)
09/01/14 Rev. A
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Peerless Faucet PTT298510
Summary of Contents for Peerless Faucet PTT298510
- Page 1 PARA BAÑERA ROMANA DE DOS MANIJAS (MANERALES) ACCESSOIRES DE FINITION DE ROBINET À DEUX POIGNÉES POUR BAIN ROMAIN Model/Modelo/Modèle PTT298510 Series/Series/Seria Write purchased model number here. Escriba aquí el número del modelo comprado. Inscrivez le numéro de modèle ici. You may need/Usted puede necesitar/Articles dont vous pouvez avoir besoin: 1/8"...
- Page 2 NOTE:The deck and valve rough-in must be finished before installing the trim kit. Unscrew the test cap (1) and discard. Screw bases (2) with gaskets (3) Install handles. NOTE: If either handle does not rotate the correct over end valves (4). Note: Discard the black gaskets and use silicone direction, do the following: under the bases for installations on uneven or rough surfaces like tile.
- Page 3 Maintenance If faucet leaks from spout outlet–Shut off water supplies– Replace Seats and Springs (1). If leak persists–Shut off water supplies–Replace Stem Unit Assembly (2).* *Install stems (2) correctly for proper handle rotation: ・ For Lever handles, the stops (3) must point to the right when installed. Mantenimiento Turn faucet handles (1) all the way on.
- Page 4 This warranty excludes all industrial, commercial, and business usage (including but not limited to use in multi-family housing), whose purchasers Peerless Faucet Company will replace, FREE OF CHARGE, during the warranty period, are hereby extended a five-year limited warranty from the date of purchase,...
