- Page 1 Electrical Mini Tank Water Heater Installation uide, ser anual, and Warranty nformation Electrical Mini Tank Water Heater 2.6 Gals...
- Page 2 IMPORTANT SAFETY INFORMATION A SAFETY VALVE MUST BE USED FOR PROPER INSTALLATION! As this water heater has a hot water reservoir, natural expansion of the contents will occur. A safety valve must be used for installation in case there is too much expansion, which would result in damage to the unit or personal injury.
- Page 3 INSTALLATION DIAGRAM & KEY INSTALLATION DIAGRAM KEY (Only 2.6 Gallon Tank and two ½” brass bushings included in Purchase) 1. ½” Tee. 2. Safety valve set at 116 PSI with funnel. 3. Reducing Tee 1 ½”x 1 ½” x 1''. 4.
- Page 4 INSTALLATION – ELECTRICAL Refer to Installation Diagram on page 2 for required hardware and General assembly. Any other installation position may result in serious damage to the appliance. Installation should take place as close as possible to a cold water connection. The product should be protected from the effects of frost (For example if installed in RVs or summer homes) Note: When tightening swivels and compression connections always use 2 open end wrenches in order to prevent bending and twisting pipes and accessories.
- Page 5 OPERATING INSTRUCTIONS Thermostat Thermostat (Operating Setting) Cold; heater is switched off. Automatic frost protection active; the device switches on if the water temperature falls below 45 F / 7 Water temperature has risen by approx. 77 F / 25 Energy-saver mode/reduced energy consumption: Greater energy savings are possible if the water temperature is set to a maximum of +/-131 (+/-55 C).
- Page 6 MAINTENANCE This device does not require any maintenance by the user. Repairs should always be carried out by a licensed contractor. A service inspection should be performed every year. Descaling of the device during this inspection is highly recommended, especially if you live in an area with hard water. Higher termperature water will intensify calcification.
- Page 7 REMARKS This appliance can be used by children and persons with reduced physical, sensory or mental capabilities if they are supervised during use of the appliance, and understand the hazards involved. The unit must be installed to independent breaker as per electrical diagram. Do not let children play with the unit.
- Page 8 2.6 Gals...
Need help?
Do you have a question about the 2.6 Gals and is the answer not in the manual?
Questions and answers
How to adjust heat
To adjust the heat on a ThermoFlow 2.6 Gals unit, follow these steps:
1. Power on the unit and ensure it is properly connected to electricity.
2. Locate the temperature setting control (refer to the operating instructions on page 4 of the manual).
3. Adjust the temperature to your desired setting.
4. Verify that the temperature indicator light turns off when the set temperature is reached.
If the water heater is in an area with extremely hard water, it is recommended to set the device at a maximum of 131°F to reduce calcification.
