Whirlpool GW395LEPB03 Parts List

For Models: GW395LEPB03, GW395LEPQ03, GW395LEPT03, GW395LEPS03
Illus. Part
No. No. DESCRIPTION
1 Literaturre Parts
9761413 Installation
Instructiions
W10086240 Use & Care Guide
9761386 Tech Sheet
9757680 Anti−Tip Instruct.
3191638 Safe Cooking Tips
9759133 Safe Cooking Tips
2 9759523 Burner Box
3 4454023 Bracket, Mounting
4 Cooktop
9760428BT Biscuit
9760428WH White
9760428BL Black
5 3400843 Screw
6 Trim−CkTop, SI
9759531WH White LH
9759531BT Biscuit LH
9759531BL Black LH
9759531SS S.Steel LH
9759530WH White RH
9759530BT Biscuit RH
9759530BL Black RH
9759530SS S.Steel RH
4−10 Litho in U.S.A. (cre)
COOKTOP PARTS
(Black) (White)
Illus. Part
No. No. DESCRIPTION
7 3196537 Screw
8 4453989 Shield, Heat
9 3192811 Bracket, Burner
10 9756821 Support, Wiring
11 9756505BL Dome Cap, Vent
12 Grate, Burner
9759756BL Black (RH)
9759756EP Espresso (RH)
9759756MG Mouse Grey (RH)
9759755BL Black (LH)
9759755EP Espresso (LH)
9759755MG Mouse Grey (LH)
13 4449809 Screw
14 3196160 Screw
16 9759944 Thermostat (60c)
17 Vent, Center
9760224BL Black
9760224WH White
9760224BT Biscuit
1
(Biscuit) (S.Steel)
Illus. Part
No. No.
18
9760520WH White
9760520BT Biscuit
9760520BL Black
9760520SS S.Steel
19
9753939GB Black
9753939EP Espresso
9753939GS Mouse Grey
3191904 Black
3191905 Mouse Grey
8273345 Espresso
3191898 Black
3191899 Mouse Grey
8273343 Espresso
23 9759629 Cover, Cktp Rear
30" Slide−In
GAS OVEN
NON−CONV
DESCRIPTION
Trim, Extension
Cap, Burner
14K (LF)
12.5K (RR)
6K (RF, LR)
Part No. 8186752
