- Page 1 FACTORY AUTOMATION MANUAL INX***DH-F199-IE2-***, INY***DH-F199-IE2-*** with Analog Interface and RS232 Programming Interface...
- Page 2 INX***DH-F199-IE2-***, INY***DH-F199-IE2-*** With regard to the supply of products, the current issue of the following document is ap- plicable: The General Terms of Delivery for Products and Services of the Electrical Indus- try, published by the Central Association of the Electrical Industry (Zentralverband Elektrotechnik und Elektroindustrie (ZVEI) e.V.) in its most recent version as well as the supplementary clause: "Expanded reservation of proprietorship"...
-
Page 3: Table Of Contents
INX***DH-F199-IE2-***, INY***DH-F199-IE2-*** Introduction................. 5 Content of this Document ..............5 Target Group, Personnel..............5 Symbols Used ..................6 Intended Use ..................6 General Safety Notes ................6 Declaration of conformity..............7 Product Description ..............8 Use and Application................8 Connection Cable for Normal Operation ........... 8 Accessories for R232 Programming .......... - Page 4 INX***DH-F199-IE2-***, INY***DH-F199-IE2-*** Programming Commands in Configuration Mode ......20 5.3.1 Retrieving a Setting ................21 5.3.2 Configuration Mode................21 5.3.3 Baud Rate ..................21 5.3.4 Output Transmission Rate ..............22 5.3.5 Moving Average Filter............... 22 5.3.6 Preset Value ..................22 5.3.7 Restore Origin ..................
-
Page 5: Introduction
INX***DH-F199-IE2-***, INY***DH-F199-IE2-*** Introduction Introduction Content of this Document This document contains information required to use the product in the relevant phases of the product life cycle. This may include information on the following: Product identification Delivery, transport, and storage Mounting and installation Commissioning and operation Maintenance and repair Troubleshooting... -
Page 6: Symbols Used
INX***DH-F199-IE2-***, INY***DH-F199-IE2-*** Introduction Symbols Used This document contains symbols for the identification of warning messages and of informative messages. Warning Messages You will find warning messages, whenever dangers may arise from your actions. It is mandatory that you observe these warning messages for your personal safety and in order to avoid property damage. -
Page 7: Declaration Of Conformity
If serious faults occur, stop using the device. Secure the device against inadvertent operation. In the event of repairs, return the device to your local Pepperl+Fuchs representative or sales office. -
Page 8: Product Description
INX***DH-F199-IE2-***, INY***DH-F199-IE2-*** Product Description Product Description Use and Application INX***DH-F199-IE2-*** and INY***DH-F199-IE2-*** series inclination sensors detect and measure the tilt angle (inclination/slope/elevation) of an object in relation to the force of gravity. The basic principle behind these inclination sensors is a microelectromechanical systems (MEMS) sensor cell that is embedded in a fully molded application-specific integrated circuit (ASIC). -
Page 9: Accessories For R232 Programming
INX***DH-F199-IE2-***, INY***DH-F199-IE2-*** Product Description Accessories for R232 Programming Device/Cable P+F type code Description Adapter cable M12 to V19-G-0,5M-PVC-SUBD9 Adapter cable from inclination sensor to Sub-D9 and power RS232 converter supply Inclintion sensor side: M12, 8-pin RS232 converter side: Sub-D9 (female) Power supply side: Hollow connector 5.5/2.1 female USB-RS232 converter –... -
Page 10: Installation
INX***DH-F199-IE2-***, INY***DH-F199-IE2-*** Installation Installation Instructions for Mechanical and Electrical Installation Observe the following instructions to ensure safe operation of the inclination sensor: Warning! Work must only be performed by trained and qualified personnel. Commissioning and operation of this electrical equipment must only be performed by trained and qualified personnel. -
Page 11: Mounting Instructions
INX***DH-F199-IE2-***, INY***DH-F199-IE2-*** Installation Mounting Instructions The inclination sensors are pre-calibrated devices that can be put into immediate operation following easy installation with a three point mount. The mounting surface must be flat and free of dust and grease. Depending on the sensor model, pay attention to the correct orientation of the sensor for inclination measurement when mounting. -
Page 12: Electrical Connection
INX***DH-F199-IE2-***, INY***DH-F199-IE2-*** Installation Electrical Connection The sensors are connected to the control system via an M12 x 1, 8-pin, male connector. INX***DH-F199-IE2-*** INY***DH-F199-IE2-*** Signal Analog output x-axis SET 1 (analog input 1) Analog output y-axis 7 (static 2.2 mA, INX* has no y-axis) SET 2 (analog input 2) Pinout... -
Page 13: Firmware Features Overview
INX***DH-F199-IE2-***, INY***DH-F199-IE2-*** Firmware Features Overview Firmware Features Overview INX***DH-F199-IE2-*** and INY***DH-F199-IE2-*** series inclination sensors can be adapted for any application by programming parameters via the RS-232 and/or analog interface. Important Factory Settings Note! Note the following factory settings carefully upon installation. Some of the parameters have to be reprogrammed to optimize the inclination sensor for measurement Description Value... -
Page 14: Operation Modes
INX***DH-F199-IE2-***, INY***DH-F199-IE2-*** Firmware Features Overview Operation Modes INX***DH-F199-IE2-*** and INY***DH-F199-IE2-*** series inclination sensors have 2 operation modes concerning the RS-232 interface. Measurement Mode The measurement mode of an inclination sensor is the free-running operational output mode, in which the position value is sent cyclically (according to the output transfer rate) using the RS- 232 interface. -
Page 15: Programmable Parameters
INX***DH-F199-IE2-***, INY***DH-F199-IE2-*** Firmware Features Overview Programmable Parameters The parameter settings of INX***DH-F199-IE2-*** and INY***DH-F199-IE2-*** series inclination sensors can be programmed via the RS-232 interface. Additionally, a few of these functionalities are also available through analog inputs SET1 and SET2. Programmable via Configuration mode Inclination sensor can be RS-232... -
Page 16: Rs232 Interface Setup And Programming
INX***DH-F199-IE2-***, INY***DH-F199-IE2-*** RS232 Interface Setup and Programming RS232 Interface Setup and Programming Electrical Connection for RS-232 Programming The following figure describes how to establish a connection between a PC and an inclination sensor via USB-RS-232 converter. Power Supply (AC 100...240 V 50/60Hz to DC 24 V, 500 mA) Inclination Sensor P+F Adapter Cable USB-RS232 Converter... - Page 17 INX***DH-F199-IE2-***, INY***DH-F199-IE2-*** RS232 Interface Setup and Programming Setup Communication 1. Start the Termite 3.4 RS-232 terminal software. Figure 5.2 Note! Baud Rate We recommend accepting the default factory baud rate. If the user forgets the adjusted baud rate, testing must be conducted to find out the new value. Resetting the baud rate to the default value is not possible.
- Page 18 INX***DH-F199-IE2-***, INY***DH-F199-IE2-*** RS232 Interface Setup and Programming 2. Set the RS-232 communication settings for your PC as displayed in the setting dialog box below. Note the settings outlined in red must always remain the same. The setting outlined in green is user-specific. Figure 5.3 3.
- Page 19 INX***DH-F199-IE2-***, INY***DH-F199-IE2-*** RS232 Interface Setup and Programming Programming by Sending Commands To start programming, switch the inclination sensor from measurement mode to configuration mode. After finalizing programming, switch from configuration mode back to measurement mode. 1. Press <Enter> to switch to configuration mode. 2.
-
Page 20: Programming Commands In Configuration Mode
INX***DH-F199-IE2-***, INY***DH-F199-IE2-*** RS232 Interface Setup and Programming Programming Commands in Configuration Mode The following table displays all programmable parameters via RS232 interface. Additionally, a few of these functionalities are programmable via analog interface. Note! Baud Rate Resetting the baud rate to the default value is not possible. If the user forgets the adjusted baud rate, testing must be done to determine the new value. -
Page 21: Retrieving A Setting
INX***DH-F199-IE2-***, INY***DH-F199-IE2-*** RS232 Interface Setup and Programming Teach-in Mode Commands Function Command Set maximum V/I at current position setmax<CR> Reset the maximum V/I to factory default clrmax<CR> position Table 5.2 5.3.1 Retrieving a Setting Function Description Command Explanation Default Retrieving a Typing a command Example: You can retrieve any parameter... -
Page 22: Output Transmission Rate
INX***DH-F199-IE2-***, INY***DH-F199-IE2-*** RS232 Interface Setup and Programming 5.3.4 Output Transmission Rate Function Description Command Parameters Default Output The transmission rate period<SP>parameter<CR> Parameters 100 ms transmission of angular values can 1 = 62.5 ms rate be adjusted. 1 = 100 ms 2 = 200 ms 3 = 500 ms 4 = 1000 ms... -
Page 23: Measurement Direction
INX***DH-F199-IE2-***, INY***DH-F199-IE2-*** RS232 Interface Setup and Programming 5.3.8 Measurement Direction Function Description Command Parameters Default Measurement Inverts measurement compl<SP>parameter<CR> 0 = clockwise only Direction direction. 1 = counterclockwise Note: Before using the command, ensure = SET 2 acitvate that the sensor is set (change only via anlog to "teach 0". -
Page 24: Analog Interface Programming
INX***DH-F199-IE2-***, INY***DH-F199-IE2-*** Analog Interface Programming Analog Interface Programming Programming of the inclination sensor via analog interface is an alternative to RS-232 programming. Note that only some functions can be SET via analog inputs SET 1 and SET 2. The following functions can be SET via analog inputs SET 1 and SET 2. Before analog programming, the analog functions must first be set via RS-232 interface to implement this function. -
Page 25: Preset Value
INX***DH-F199-IE2-***, INY***DH-F199-IE2-*** Analog Interface Programming Programming via analog inputs SET 1 and SET 2 1. Connect the operating voltage to pins 1 and 4 of the M12x1, 8-pin connector. 2. Apply a positive voltage (5 V ... 30 V, Rin > 110 KΩ) on the relevant inputs SET 1 and/or SET 2 for at least 100 ms for programming a function. -
Page 26: Scaling Of Output
INX***DH-F199-IE2-***, INY***DH-F199-IE2-*** Analog Interface Programming Scaling of Output To use this analog programming option, the inclination sensor must first be set to the teach-in mode (teach 1) via RS-232 interface. Scaling of output can be set based on a user-defined angular measuring range. The range is defined by the 2 set points created by analog teach-in inputs SET 1 and SET 2. - Page 27 Twinsburg, Ohio 44087 · USA Tel. +1 330 4253555 E-mail: sales@us.pepperl-fuchs.com Asia Pacific Headquarters Pepperl+Fuchs Pte Ltd. Company Registration No. 199003130E Singapore 139942 Tel. +65 67799091 E-mail: sales@sg.pepperl-fuchs.com www.pepperl-fuchs.com Subject to modifications / TDOCT-6390 Copyright PEPPERL+FUCHS • Printed in Germany 04/2019...
