Technical Specifications - Oracle MICROS 700 Series Setup Manual

Table 1-4
Feature
A. Barcode Scanner (Optional)
B. Magnetic Stripe Reader (MSR)
C. Headphone Jack
D. USB 2.0 Port
E. 5V DC Power Input
Table 1-5
Feature
1. Power Button
2. Scanner Trigger
3. Battery/Power LED
4. Battery Latch
5. Battery Sensor

Technical Specifications

The following tables contains the technical specifications for the Oracle MICROS
Tablet 720, Oracle MICROS Tablet 721, and Oracle MICROS Tablet 721P.
Table 1-6
Feature
Processor
RAM
Storage
Operating System
Display
Input/Output Port on the Oracle MICROS Tablet 720
Button Functions on the Oracle MICROS Tablet 720
Technical Specifications for the Oracle MICROS Tablet 720
Technical Specifications
Description
Captures and reads information contained in a
bar code.
Reads the information encoded in the
magnetic stripe of payment cards.
Use to connect a headphone, a microphone,
or a headset.
Use to connect peripherals such as storage
devices, printers, and displays.
Use to connect a power adapter to provide
power to your tablet and charge the battery.
Description
Turns the tablet on or off.
Use to activate the barcode scanner.
Indicates the power and battery status.
Battery LED Status has more information on
the behavior of the LED.
Use to unlock and remove the battery.
Senses the presence of a battery. Located in
the battery compartment under the battery.
Inadvertently pressing this when the battery is
removed disables the "hot swap" capability
and causes the tablet to power off.
MICROS Tablet 720
Intel Atom Quad Core, 1.33GHz
2GB
64GB Flash
Microsoft Windows Embedded 8.1 Industry
Pro
Microsoft Windows 10 IoT Enterprise 2016
LTSB
7-inch LED-Backlight Screen with Capacitive
Touch
Chapter 1
1-6
