Summary of Contents for Intelligent Home Thor
- Page 1 Video Door Entry System user manual CALL UNLOCK TALK/MON IN-USE Thor www.intelligenthomeonline.com...
- Page 2 PRECAUTIONS ● Read this manual through before using the product. ● Slots or openings in the back of the monitor, are provided for ventilation and to ensure reliable operation of the video monitor or equipment and to protect if from overheating. These openings must not be blocked or covered.
-
Page 3: Table Of Contents
CONTENT 1. Monitor Parts and Functions - - - - - - - - - - - - - - - - - - - - - - - -1 2. Monitor Mounting - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -1 3. -
Page 4: Monitor Parts And Functions
1. Monitor Parts and Functions LCD Touch Screen Microphone CALL CALL button UNLOCK UNLOCK button TALK/MON TALK/MON button IN-USE LED indicator Speaker Ventilation Vent Extending port BUS port DIPS 1 2 3 4 5 6 DIP switch 2. Monitor Mounting Use the screws to fix the Mounting Bracket on the wall.(fitting accesories includes a Bracket ) Wire the system correctly(see the later connection chapter) then hang the Monitor on the Mounting Bracket firmly. -
Page 5: System Connection
3. System Connection Monitor Camera UNLOCK INTERCOM MON/TALK IN-USE Note 3 Note 1 Note 4 DIPS L1 L2 PL S1+ S2+ S- Note 2 1 2 3 4 5 6 Note 5 Note 6 ● Note 1: Mount the DPS and PS5 side by side on the DIN nail or on the wall. ●... -
Page 6: Multiple Monitors Connection(Optional)
4. Multiple Monitors Connection(optional) Note 1 Note 2 Note 3 Note 4 1# Monitor 2# Monitor 3# Monitor 4# Monitor UNLOCK UNLOCK UNLOCK UNLOCK INTERCOM INTERCOM INTERCOM INTERCOM MON/TALK MON/TALK MON/TALK MON/TALK IN-USE IN-USE IN-USE IN-USE DIPS DIPS DIPS DIPS 1 2 3 4 5 6 1 2 3 4 5 6 1 2 3 4 5 6... -
Page 7: Multiple Door Cameras Connection(Optional)
5. Multiple Door Cameras Connection(optional) Note 1 UNLOCK UNLOCK UNLOCK UNLOCK INTERCOM INTERCOM INTERCOM INTERCOM MON/TALK MON/TALK MON/TALK MON/TALK IN-USE IN-USE IN-USE IN-USE DIPS DIPS DIPS DIPS 1 2 3 4 5 6 1 2 3 4 5 6 1 2 3 4 5 6 1 2 3 4 5 6 4# Camera 3# Camera... -
Page 8: Talk/Unlock Operation
6. Talk/Unlock Operation When visitor presses the Call Button on the Outdoor Station, the Monitor(s) will ring, at the same time, the screen displays the visitor image. CALL Standard UNLOCK Screen TALK/MON Unlock IN-USE Talk Capture Name A Name B Home Press TALK/MON Button or icon, you can talk with the visitor for 90 seconds. -
Page 9: Ring Tone Setting
8. Ring Tone Setting 9. Ring Volum Setting You can set a ring volume for day time,6:00 12 pieces ring tone can be selected. When AM~18:00 PM is the day time by default. the Monitor is in standy, press anywhere Touch the scteen tiwce to enter home on the screen, a full screen calendar will be screen page, then touch... -
Page 10: Intercom
10. Intercom On the Information page, press the screen on hold for 2 seconds to enter the page When multiple monitors are installed, below: intercom function is available. Intercom can be initiated by either Monitor. Press the CALL CALL Button, then touch the Inner Call UNLOCK icon the other Monitor will ring. -
Page 11: Monitor Time Setting
12. Monitor Time Setting 13. Screen Setting Monitor Time is the maximum monitoring When the Monitor is in monitoring or talking time when the TALK/MON Button is pressed Adjust icon to enter screen state, Press in standby, after which the screen will be setting page.Touch any item you want,then closed automatically. -
Page 12: Built-In Memory And Sd Card
15. Built-in Memory and SD Card This Monitor has been equipped with a built-in memory (about 120 MB) together with a SD card reader. Maximum 16 GB SD card can be supported. CALL UNLOCK TALK/MON IN-USE SD card ● The monitor can play photos and pictures. ●... - Page 13 15.1 Picture Recording Both Auto-Recording and Manual-Recording are available.and Auto-Recording is default. If CALL 00:03 Talking receive a Call , after 3s, the monitor will record Standard UNLOCK Screen TALK/MON Unlock automatically. or you can touch Capture IN-USE Talk icon to record the visitor's image manually. Capture Recording...
- Page 14 15.4 Photo Frame Playing Touch Album icon on home screen to play the photos.it can be played both manually and automatically,use your fingers to slide right or left on screen to play last/next photo. 15.5 Playing time setting Touch Multi Media icon on home screen to enter next page, touch Album Options icon,a digital CALL keypad will be showed on the screen,then you...
-
Page 15: Connection Other Device To Monitor
16. Connection Other Device to Monitor 8.1 Connect Doorbell call button Additional door bell call button can be connected to the Monitor, so that the visitors can ring the door bell again in front of the user's apartment. EXT-RING When the call button is pressed, the Monitor will Door bell call button VIDEO output ring tones but the screen will keep off, and... -
Page 16: Specifications
17. Specifications ● Power supply for indoor monitor: DC 24V (supplied by Adaptor) ● Power consumption: Standby 0.5W; Working status 15W ● Monitor screen: 7 Inch color TFT-LCD ● Display Resolutions: 1,440(R, G, B) x 234 pixels ● Built-in Memory: 118 MB(only for DT692SD) ●... - Page 17 - 1 4 -...
- Page 19 4. Attempting to force the device to perform functions for which it is not intended 5. Attaching the device to power supplies other than thoserecommended by the manufacturer Distributor for Warranty purposes: Intelligent Home Online Ltd 34a High Street Hornsey London...
- Page 20 DT-Thor-villa-V1 2010-11-12 The design and specifications can be changed without notice to the user. Right to interpret and copyright of this manual are preserved. www.intelligenthomeonline.com...
