Connector Pinouts

TM
HawkEye
1600T Connectors
Power & Primary I/O Connector
Figure A–1 shows the pinout of the Power and Primary I/O connector.
FIGURE A–1.
Power &
Primary I/O
Connector
Table A–1 lists the supplier for the Power and Primary I/O connector mating
connector and cable.
TABLE A–1.
Supplier
Part Number
Siemens
6GF0310-0HT00-0CP0
Table A–2 describes the Power and Primary I/O connector signals.
TABLE A–2.
Pin
Short Designation
1
OUT1
2
OUT2
3
OUT3
4
Power Input
5
Out Common
A-2
Power & Primary I/O Connector "X1" - Rear View
X1
2
3
8
4
5
6
Power & Primary I/O Connector Mating Cable
Description
Connector Type M12 8 Pin A Coded, Female Cable
10M
Power & Primary I/O Connector Signals
Direction
Out
Out
Out
In
SIMATIC HawkEye™ 1600T Smart Camera Guide
1
7
Function
S/W Programmable
S/W Programmable
S/W Programmable
Fused +24V, 1 Amp max.
Output Common
Notes
3
3
3
1
4
Rev. 1E, Nov 2007
