Chapter
2
System Components

Mounting Using Standard Mounting Block

You can mount the SIMATIC HawkEye™ 1600T using the standard mounting
bloc (see Figure 2–7).
FIGURE 2–6.

Mounting Using Accessory Mounting Block

You can mount the SIMATIC HawkEye™ 1600T using the accessory mounting
block (see Figure 2–7). The backward compatible mounting block positions a
SIMATIC HawkEye™ 1600T in the same position as a SIMATIC HawkEye™
1600 for optical alignment.
FIGURE 2–7.
2-12
Standard Mounting Block
Part Number - 6GF0310-0HT00-0CM1
Accessory Mounting Blocks
Part Number - 6GF0310-0HT00-0CM2
SIMATIC HawkEye™ 1600T Smart Camera Guide
Rev. 1E, Nov 2007
