Summary of Contents for Cartoni Focus 22
- Page 1 PROFESSIONAL CAMERA SUPPORT USER’S MANUAL & Maintenance...
- Page 3 & S afety ntrodUctIon peratIng elementS rocedUreS pecIfIcatIonS aIntenance arranty & cceSSorIeS prodUct lIne CARTONI ® All rights reserved © Manual Version: 2.3 Issue date: March 2020...
- Page 5 FOCUS 22, weighs only 3,9 kg (8.6 lbs) thanks to the extensive use of extremely lightweight magnesium alloys. The FOCUS 22 interfaces with all 100 mm bowl base tripods. In the FOCUS 22/150 version, it interfaces with the all 150 mm bowl base Tri- pods and with Pedestals through the standard Vinten 4 bolts.
-
Page 6: Operating Elements
2. o peratIng lementS ❶ ❷ ❹ ❸ ❺ ❼ Camera plate ❻ Sliding Camera platform Pan bar attachment Pan bar extension Pan drag selector Pan brake lever Tilt brake lever... - Page 7 ⓬ ⓫ ❿ ⓰ ⓯ Tie down knob ⓭ ❻ Removable tie down shaft Camera plate release lever ⓮ ❽ Safety button Sliding platform lock Tilt drag selector Illuminated spirit level Counterbalance selector ❾ Pan bar...
- Page 8 3. p rocedUreS Place the FOCUS 22 on your Tripod by loosening the tie-down knob (8) under the Fluid Head and level using the illuminated spirit level (14). In low light conditions, press button for light. Connect the Pan bar (16) to the Fluid Head tightening the lever (3) on the Pan bar attachment and select your desired operating angle.
-
Page 9: Specifications
Unlock the Pan brake lever (6) and set the Fluid drag control by adjust- ing selectors (5 & 13). The FOCUS 22 can be attached to most of the sliders via a 3/8” tread- ed hole under the Head. Remove the tie down shaft (9) with a M10 key and find the hole underneath. -
Page 10: Maintenance
5. m aIntenance With indoor use - when needed - just clean the FOCUS 22 and Tripod with a soft cloth. Dirt accumulated during storage may be removed using a brush or Air spray. CARTONI products main mechanisms are sealed as they are also built for professional outdoor use. - Page 11 This warranty does not apply to any CARTONI product that has been damaged in shipping or handling, abused, misused, operated contrary to instructions for use, neglected, normal wear or tear, modified or changed in design or construction or serviced by unauthorized parties.
- Page 12 PROFESSIONAL CAMERA SUPPORT CARTONI S.p.A Via di Portonaccio, 33/B - 00159 Rome (Italy) Phone +39 06 4382002 Fax +39 06 43588293 Email: cartoni@cartoni.com www.cartoni.com...
