- Page 1 UNDERCOUNTER DISHWASHER Use & Care Guide For questions about features, operation/performance, parts, accessories or service, call: 1-800-253-1301. or visit our website at... www.estateappliances.com Table of Contents ...2 Model TUD6700P 3385811...
-
Page 2: Table Of Contents
TABLE OF CONTENTS DISHWASHER SAFETY ...3 Before Using Your Dishwasher...4 PARTS AND FEATURES...5 START-UP GUIDE ...6 Using Your New Dishwasher ...6 Stopping Your Dishwasher ...6 DISHWASHER LOADING...6 Loading Suggestions ...6 Loading Top Rack...7 Loading Bottom Rack ...7 Loading Silverware Basket ...8 DISHWASHER USE ...8 Detergent Dispenser ...8 Rinse Aid Dispenser ...9... -
Page 3: Dishwasher Safety
Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow the safety alert symbol and either the word “DANGER”... -
Page 4: Before Using Your Dishwasher
Before Using Your Dishwasher Tip Over Hazard Do not use dishwasher until completely installed. Do not push down on open door. Doing so can result in serious injury or cuts. Electrical Shock Hazard Electrically ground dishwasher. Connect ground wire to green ground connector in terminal box. -
Page 5: Parts And Features
A. Third level wash B. 3 position rack adjusters C. Top spray arm D. Bottom rack E. Filter module F. Water inlet opening (in tub wall) Control Panel PARTS AND FEATURES G. Heating element H. Rack bumper I. Vent J. Top rack K. -
Page 6: Start-Up Guide
START-UP GUIDE Before using your dishwasher, remove all packaging materials. Read this entire Use and Care Guide. You will find important safety information and useful operating tips. Using Your New Dishwasher 1. Scrape large food soil and hard items (toothpicks or bones) from dishes. -
Page 7: Loading Top Rack
Loading Top Rack The top rack is designed for cups, glasses, and smaller items. (See recommended loading patterns shown.) NOTE: The features on your dishwasher rack may vary from the drawings shown. Do not cover third level spray. See arrow. Cup and glass load Mixed load Place items so open ends face down for cleaning and... -
Page 8: Loading Silverware Basket
Utensil load Load cookie sheets, cake pans, and other large items at the sides and back. Loading such items in front can keep the water spray from reaching the detergent dispenser and silverware basket. Secure heavily soiled cookware face down in the rack. Make sure pot handles and other items do not stop rotation of the spray arm(s). -
Page 9: Rinse Aid Dispenser
Where to fill Top of 3rd step (9 tsp or 45 mL) Top of 2nd step (6 tsp or 30 mL) Top of 1st step (3 tsp or 15 mL) Soft to Medium Water (0-6 grains per U.S. gallon) [typical water softener water and some city water] Soil Level Main Wash Lightly soiled/Pre-... -
Page 10: Cycle Selection Charts
Use the energy-saving dry option whenever possible. Allow longer drying times (overnight) when using these options. Use a rinse aid to improve drying. Use cycles or options that add extra heat to the wash or rinse portion of the cycle only when needed. Run your dishwasher with full loads. -
Page 11: Canceling A Cycle
Canceling a Cycle You can cancel a cycle at any time. 1. Turn the cycle control knob slowly clockwise until you hear water draining. Let the dishwasher drain completely. 2. Open the door. 3. Turn the cycle control knob to Off. Changing a Cycle or Setting You can change a cycle anytime during a cycle. -
Page 12: Washing Special Items
If you have doubts about washing a particular item, check with the manufacturer to see if it is dishwasher safe. Material Dishwasher Safe?/Comments Aluminum High water temperature and detergents can affect finish of anodized aluminum. Disposable Aluminum Do not wash throwaway aluminum pans in the dishwasher. -
Page 13: Dishwasher Care
Cleaning Cleaning the exterior In most cases, regular use of a soft, damp cloth or sponge and a mild detergent is all that is necessary to keep the outside of your dishwasher looking nice and clean. If your dishwasher has a stainless steel exterior, a stainless steel cleaner is recommended. -
Page 14: Troubleshooting
First try the solutions suggested here and possibly avoid the cost of a service call... Dishwasher is not operating properly Dishwasher does not run or stops during a cycle Is the door closed tightly and latched? Is the right cycle selected? Refer to the “Cycle Selection Charts.”... -
Page 15: Assistance Or Service
Whirlpool designated service technicians are trained to fulfill the product warranty and provide after- warranty service, anywhere in the United States. To locate the Whirlpool designated service company in your area, you can also look in your telephone directory Yellow Pages. -
Page 16: Warranty
For ten years from the date of purchase, when this dishwasher is operated and maintained according to instructions attached to or furnished with the product, Whirlpool Corporation will pay for FSP or inner door if either develops a water leak resulting from defective materials or workmanship. Service must be provided by a Whirlpool designated service company.
