Whirlpool WED7500V Dimensions And Installation Information

Whirlpool electric dryer specification sheet.
Hide thumbs


Advertisement

®

Electric Dryer

PRODUCT MODEL NUMBERS
WED7500V
Electrical: A four-wire or three-wire, single phase,
120/240-volt, 60 Hz, AC-only, electrical supply (or
120/208-volt electrical supply, if specified on the
serial/rating plate) is required on a separate 30 amp
circuit, fused on both sides of the line. A time-delay
fuse or circuit breaker is recommended.
Exhaust venting: Exhaust your dryer to the
outside. 4" (10.2 cm) diameter vent is required.
Heavy metal exhaust vent must be used. Do not use
plastic or metal foil vent. Exhaust outlet hood must
be at least 12" (30.5 cm) from the ground or any
object that may be in the path of the exhaust.
CUSTOM UNDERCOUNTER, RECESSED AREA AND
CLOSET INSTALLATION
Custom undercounter installation - Dryer only
0"
(0 cm)
33¹⁄₄" min.
(84.45 cm)
0"
(0 cm)
(59.37 cm)
Recessed or closet installation - Dryer only
14"
(35.6 cm)
18"(45.7cm)
3"
(7.6 cm)
0"
1" (2. 5 cm)
(0 cm)
A
A. Side view - closet or confined area
B. Recessed area
C. Closet door with vents
Recessed or closet installation - Stacked with stack kit (Accessory)
12"
(30.5 cm)
DRYER
WASHER
0" (0 cm)
0" (0 cm)
1" (2.5 cm)
A
B
A. Recessed area
B. Side view - closet or confined area
C. Closet door with vents
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
OVERALL DIMENSIONS
23³⁄₈"
0"
(0 cm)
3"
(7.6 cm)
2
48 in.
2
(310 cm
)
2
24 in.
3"
2
(155 cm
)
(7.6 cm)
0"
(0 cm)
B
C
3" (7.6 cm)
3"
(7.6 cm)
2
48 in.
2
(310 cm
)
2
24 in.
3"
2
(155 cm
)
(7.6 cm)
C
39"
(99.1 cm)
23³⁄ ₈ "
(59.37 cm)
EXHAUST VENTING
Vent material
• Use a heavy metal vent. Do not use plastic or metal foil vent.
• 4" (10.2 cm) heavy metal exhaust vent and clamps must be used.
Rigid metal vent
• For best drying performance, rigid metal
vents are recommended.
• Rigid metal vent is recommended to
avoid crushing and kinking.
Flexible metal vent
• Flexible metal vents are acceptable only if accessible for cleaning.
• Flexible metal vent must be fully extended and supported when the dryer is in its
final location.
• Remove excess flexible metal vent to avoid sagging and kinking that may result
in reduced airflow and poor performance.
Exhaust
Recommended hood styles are shown here.
The angled hood style (shown here) is acceptable.
• An exhaust hood should cap the vent to keep rodents and insects from entering
the home.
• Exhaust hood must be at least 12" (30.5 cm) from the ground or any object that may
be in the path of the exhaust (such as flowers, rocks or bushes, snow line, etc.).
• Do not use an exhaust hood with a magnetic latch.
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
*
23 ¼"
(60.3 cm)
33 ¼"
(84.45 cm)
* Most installations require a
minimum 5 -1/2" (14.0 cm)
clearance behind the dryer for
the exhaust vent with elbows.
10.2 cm
4" (10.2 cm) heavy metal exhaust vent
B
A
4"
(10.2 cm)
4"
(10.2 cm)
A. Louvered hood style
B. Box hood style
4"
(10.2 cm)
2½"
(6.4 cm)
4"
Ref. W10189310
04-02-08
