Whirlpool ACC602XP0 Use And Care Manual

Whirlpool corporation room air conditioners use and care guide room air conditioners
Hide thumbs

Advertisement

..<.q
-i
.I&
: -z;xi'l.J',r;.
_
lvens, Compactors,
Room Air Conditioners,
Dehumidifiers,
Automatic
Washers, Clothes Dryers, Freezers, Refrigerator-Freezers,
Ice Makers,Dishw:

Advertisement

Table of Contents
loading

  Related Manuals for Whirlpool ACC602XP0

  Summary of Contents for Whirlpool ACC602XP0

  • Page 1 ..<.q .I& : -z;xi’l.J’,r;. lvens, Compactors, Room Air Conditioners, Dehumidifiers, Automatic Washers, Clothes Dryers, Freezers, Refrigerator-Freezers, Ice Makers,Dishw:...
  • Page 2 Contents page Cleaning and Caring for Your , ... Air Conditioner Cooling Load Guide Self-Service Checklist Service Information @ 1985 Whirlpool installed. size for the area you want connected to electricity. electrically grounded. used only for the job it was or anyone maintained.
  • Page 3 Electrical Requirements For Your Air Conditioner ELECTRICAL REQUIREMENTS ARE DIFFERENT FOR THE MODELS SHOWN COVER, DEPENDING ON THE AMPERE RATING OF YOUR UNIT. THE NUMBER OF AMPERES PRINTED ON THE SERIAL PLATE, ATTACHED TO THE FRONT OF THE UNIT, BEHIND THE FRONT PANEL (SEE PAGE 2).
  • Page 4 INSTALLATION INSTRUCTIONS for Your Air Conditioner Unpack the mounting parts that came with your air conditioner to determine which window installation instruction If you have these parts, follow: INSTRUCTION (below). Installation Instructions CAUTION: Be sure air conditioner does not fall out of window during installation.
  • Page 5 Pick the right window. First, room(s) want to cool. window that will allow the air-conditioned to flow freely and directly you want cooled. Remember, move air around corners. If the inner sliding window slides to the left, installed on the right. Remove window there is one.
  • Page 6 Install shelf 2-3/8” from opening (see Figure 9). Measure height of opening Subtract 20-9116 ” from This will be the actual height panel Figure 9 Measure out the distance from mark it along the 20-l ‘4” side of translucent panei. Clamp panel between appropriate supporting surface close to mark...
  • Page 7 Using l/8” drill, install 7). Use two screws in top jamb and in the side bottom flanges (see Figure additional holding strength, screws at upper sides of filler “A”). Also, two screws can be added at unit sides (marked “B”). However, screws at “B”, you must use a 3 ‘16”...
  • Page 8 Figure 19 15-112” MIN. UNIT 14-112” CENTER UNIT IN AVAILABLE OPENING Drill g/64” holes in the window line up with holes in filler 19). Use two thread cutting to secure unit. If you need additional ing strength, add to screws at the bottom unit side channels page 7).
  • Page 9 Remove the glass from selected. Clear away Before sliding unit through opening, remove the bottom (Item 3) on both sides of the unit. only the top screws (Item removed. Check the knurled knob screws to see that the top mounting brackets (Item 5) are retracted to the center of the unit.
  • Page 10 HOW TO START AND USE YOUR AIR CONDITIONER EXHAUST FAN SPEED CONTROL CONTROL Be sure air conditioner it in. To Start Your Air Conditioner Set exhaust control (if your unit is so equip- ped) to CLOSED for maximum Choose either LO COOL or HI COOL speed setting.
  • Page 11 . To circulate room air Set exhaust control to CLOSED. control to FAN ONLY. CLOSED ONLY Changing Air Direction The louvers in the grille area at the top of the air conditioner control the direction If your unit looks like Figure 28, move the lever at top of the grille to the right, left or straight ahead.
  • Page 12 ,.~._ Cleaning Air Conditioner Filter filter is cleanable. A clean filter remove dust, lint and other particles from the air. Check every two weeks to see if filter needs cleaning. Remove filter by releasing clips as shown in Figure 32 or 33 (depending on your model).
  • Page 13 Oiling of the Fan Motor the fan motor per instructions motor. To add oil, pull out the oil hole plug at each end of the motor. (see Figure 34). OIL PLUGS An easy to use one-ounce capsule of especially recommended (Part No.
  • Page 14 COOLING LOAD GUIDE-SQUARE ROOM AIR CONDITIONERS To make sure you choose METHOD In e~praure WIWIXS shading lnsulallon and bulldlng construction 2000 I800 1600 I400 1200 1000 INSTRUCTIONS: 1. Determine lhe area to be cooled I” square feet and locate lhal polnl on lhe left side of chart 2.
  • Page 15 If you need assistance Call the Whirlpool COOL-LINE@ service assistance telephone number. Dial free from: Continental U.S..(800) 253-1301 Michigan .
  • Page 16 0 1985 Whirlpool Corporation Printed in U.S.A. Part No. 203873/950491 Rev. A Ranges, Micr !ifiers, Automatic Washers, Clothes Dryers, Refrigerator-Freezers, Ice Makers, Dishwashers, Built-In Ovens and Surface Units, Freezers,...
