f i r e - p a r t s . c o m
This appliance is a domestic room heating appliance. It must not be used for any other purpose
such as drying clothes etc.
Model 722AN - for Natural Gas
Model 722AP - for Propane Gas
GAS FIREPLACE
ADORN
With
INSTALLATION
AND OWNER'S
MANUAL
WARNING: If the
information in these
instructions is not followed
exactly, a fire or explosion
may result causing property
damage, personal injury or
death.
Do not store or use gasoline or other flammable vapors
-
and liquids in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
-
• Do not try to light any appliance
• Do not touch any electrical switch
• Do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas suppliers instructions.
If you cannot reach your gas supplier, call the fire
•
department.
- Installation and service must be performed by a qualified
installer, service agency or the gas supplier
VISAGE
or
Please read this manual before
installing and operating.
Fire Front
600A727/09
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Valor 722AP
Summary of Contents for Valor 722AP
- Page 1 Model 722AN - for Natural Gas Model 722AP - for Propane Gas GAS FIREPLACE ADORN VISAGE With Fire Front INSTALLATION Please read this manual before AND OWNER’S installing and operating. MANUAL f i r e - p a r t s . c o m...
-
Page 2: Table Of Contents
CONTENTS Page Safety information Options General data Location in the room Supply gas Pack contents Pre-installation appliance preparation Gas supply line installation Convection box installation Gas supply connection Ceramic walls installation f i r e - p a r t s . c o m Front &... -
Page 3: Safety Information
SAFETY INFORMATION Due to high temperatures, the appliance should be Keep the appliance area well clear and free from located out of traffic and away from furniture and combustible materials, gasoline other draperies. flammable vapors and liquids. If any changes are made to the room construction Children and adults should be alerted to the in the vicinity of the appliance after installation hazards of high surface temperatures and should... -
Page 4: Options
The minimum clearances from any combustible vent.. constructions at the front of the appliance are shown in fig.2. These front clearances apply for all installations Ratings (except where used with approved Valor Cast Suite). 722AN 722AP Altitude (Ft) 0-4500 4.2 Enclosures constructed with combustible materials Input Max. - Page 5 “VISAGE” E FROM FRONT BASE OF HEATER 53” with appliance as supplied “ADORN” “B” FRONT see page 4 for Valor Cast Suite application 43” with kit #721CRB Fig. 2 Clearances to combustible materials in front of opening - All installations...
-
Page 6: Supply Gas
Fig. 3 ~775ZCK Zero clearance kit enclosure SUPPLY GAS Model 722AN is for use only with natural gas. Model 722AP is for use only with propane gas. The supply pressure must be between the limits shown in section 3 of this manual. -
Page 7: Pack Contents
Pack 2 - “Adorn” Fire Front contains: PACK CONTENTS Fire front surround with sliding control The complete appliance is contained in two packs. Ashpan cover casting Pack 1 - Fire Unit contains: Safety guard Burner & Convection box Unit Canopy shield Ceramic back wall Thread cutting screws for canopy shield Pair of ceramic side walls... -
Page 8: Pre-Installation Appliance Preparation
APPLIANCE PRE-INSTALLATION Sparks should be seen tracking from the electrode pin to the thermocouple tip (see figure 7). PREPARATION If there are no sparks make the following checks. Check ignition spark Check condition of battery and that it is Before attempting to install, it is worth checking that correctly fitted. -
Page 9: Gas Supply Line Installation
Remove the vent connection unit. GAS SUPPLY LINE Detach the vent connection unit from the top of the INSTALLATION appliance case by removing the screw at front. Slide the vent connection unit back and lift clear (see Gas connection to the appliance is 3/8”NPT. fig.10). -
Page 10: Convection Box Installation
CONVECTION BOX INSTALLATION If installing to masonry fireplace 9.1.1 Place the convection box centrally in the fireplace opening in the position in which it is to be permanently installed. nsert the convection box into the fireplace opening feeding the supply pipe through aperture at back of the convection box. -
Page 11: Gas Supply Connection
Fit the ceramic side walls against the side faces of 10. GAS SUPPLY CONNECTION the burner compartment. The bottom edges of the walls should rest on the ledges at the sides of 10.1 Fit the gas valve and connector unit to the supply the fire box and the top of the walls should locate line. - Page 12 “Visage” front; Carefully lift the front surround. Do 12.4 Align the hole near the bottom of the control linking bar with that in the control pivot bracket. not lift it by the control knob. Place it against the Join them with the knurled shouldered screw (See fireplace front surface so that the two retaining plates at the back of the surround are directly above figure 21).
-
Page 13: Ceramic Coals Installation
13. CERAMIC COALS INSTALLATION 13.1 Place the ceramic base coal in the burner burner plaques and touch the spacers (See figure 22). compartment. The bottom rear face of the coal For LPG (propane) appliances the bottom front edge should rest on the angled ledge at the back of the of the coal base should locate directly behind the recess burner compartment. - Page 14 13.4 Find the front right multiple coal block. It is The hole in the block must locate in the round peg marked “R” underneath. Place it at the right side. at right of the base coal (See figure 25). Fig. 25 Front right multiple coal installation 13.5 Find the rear multiple coal.
-
Page 15: Operation Checks
14.4.1 Open the gas valve. Place the ashpan cover in 14. OPERATION CHECKS position below the fire front casting. 14.4.2 Light the appliance and set the slide control to high 14.1 Check reference pressure heat. The appliance is pre-set to give the correct heat 14.4.3 Leave the appliance on for five minutes. -
Page 16: Safety Guard Fitting
15. SAFETY GUARD FITTING 15.1 “Adorn” front; Locate the guard bottom wires over the brass ashlip. Hold the top springs down. Swing the guard back. Release the springs so that they locate behind the canopy (See figure 30). f i r e - p a r t s . c o m Figure 30 Fitting “Adorn”... -
Page 17: Operating Instructions
16. OPERATING INSTRUCTIONS 16.1 The flame sensing device. 16.4 Checks For your safety, your fireplace is fitted with a 16.4.1 A periodic visual check of the pilot and burner mechanism, which will automatically shut off the flames should be made. Compare the burner flames gas supply to the fire if the pilot flame goes out. -
Page 18: Lighting Instructions
16.5 Lighting instructions FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot which must be lighted by hand. When lighting the pilot, follow these instructions exactly. -
Page 19: Servicing
17. SERVICING If you require any attention to your appliance, contact your supplier quoting the model number. It will be helpful if the appliance serial number can also be quoted. This is on the chained rating plate visible when the ashpan cover is removed. The repair parts are shown in the separate repair parts leaflet. - Page 20 HEATING BIRMINGHAM, ENGLAND f i r e - p a r t s . c o m Because our policy is one of constant development and improvement, details may vary slightly from those given in this publication. © Valor Ltd.
